Tripp Lite by Eaton SmartOnline SV60KM3P3B 60kVA Tower UPS - SV60KM3P3B - Double Conversion Online UPS, 120 V AC,230 V AC, Tower, Pure Sine Wave, 120 V AC,230 V AC, Hardwired, SmartOnline SV, 8 Minute, 3.90 Minute, 60 kVA

Tripp Lite by Eaton SmartOnline SV60KM3P3B 60kVA Tower UPS - SV60KM3P3B - Double Conversion Online UPS, 120 V AC,230 V AC, Tower, Pure Sine Wave, 120 V AC,230 V AC, Hardwired, SmartOnline SV, 8 Minute, 3.90 Minute, 60 kVA-UPSPLUSBATTERY

Tripp Lite by Eaton SmartOnline SV60KM3P3B 60kVA Tower UPS - SV60KM3P3B - Double Conversion Online UPS, 120 V AC,230 V AC, Tower, Pure Sine Wave, 120 V AC,230 V AC, Hardwired, SmartOnline SV, 8 Minute, 3.90 Minute, 60 kVA

/
  • Delivery across Canada
  • In stock, ready to ship
  • Inventory on the way
Call us if you need a quote - particularly for out of stock items.
Product Features:
  • Brand: Tripp Lite by Eaton
  • Product Type: Double Conversion Online UPS
  • Manufacturer Part Number: SV60KM3P3B
  • Input Voltage: 120 V AC,230 V AC
  • Form Factor: Tower
  • Waveform Type: Pure Sine Wave
  • Plug/Connector Type: Hardwired
  • Product Family: SmartOnline SV
  • Backup/Run Time (Half Load): 8 Minute
  • Backup/Run Time (Full Load): 3.90 Minute
  • Load Capacity: 60 kVA

    • Marketing Information: The SV60KM3P3B SmartOnline® SV Series 60kVA 3-Phase On-Line Double-Conversion UPS System delivers true scalability and offers the highest level of secure, uninterrupted power protection. Featuring a modular, scalable design with high-efficiency voltage and frequency independent (VFI) operation, this on-line UPS system is ideal for protecting a variety of critical IT systems.

    The SV60KM3P3B includes pre-installed input, bypass and output breakers, as well as a static transfer switch (STS), three 20kVA SV20PM power modules and three SVBM battery modules. Space is included for one additional user-installable SV20PM power module and one SVBM internal battery module. External ±120VDC battery options, such as BP240V370, are also available from Tripp Lite for even more extended runtime.

    The Java-free HTML5-based WEBCARDLX interface enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network.

    With up to 92% efficiency in standard mode and up to 99% efficiency in optional economy mode, this 60kVA UPS system helps you reduce operating and cooling costs. Automatic and manual bypass options keep connected equipment operational during routine maintenance or critical power module failure. Front-panel display offers full UPS condition and status reporting.

Product Specifications:
Product Features:
  • Manufacturer:Eaton Corporation
  • Manufacturer Part Number:SV60KM3P3B
  • Manufacturer Website Address:https://tripplite.eaton.com/
  • Brand Name:Tripp Lite by Eaton
  • Product Line:SmartOnline
  • Product Series:SV
  • Product Model:SV60KM3P3B
  • Product Name:SmartOnline SV60KM3P3B 60kVA Tower UPS

    • Marketing Information:The SV60KM3P3B SmartOnline® SV Series 60kVA 3-Phase On-Line Double-Conversion UPS System delivers true scalability and offers the highest level of secure, uninterrupted power protection. Featuring a modular, scalable design with high-efficiency voltage and frequency independent (VFI) operation, this on-line UPS system is ideal for protecting a variety of critical IT systems.

    The SV60KM3P3B includes pre-installed input, bypass and output breakers, as well as a static transfer switch (STS), three 20kVA SV20PM power modules and three SVBM battery modules. Space is included for one additional user-installable SV20PM power module and one SVBM internal battery module. External ±120VDC battery options, such as BP240V370, are also available from Tripp Lite for even more extended runtime.

    The Java-free HTML5-based WEBCARDLX interface enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network.

    With up to 92% efficiency in standard mode and up to 99% efficiency in optional economy mode, this 60kVA UPS system helps you reduce operating and cooling costs. Automatic and manual bypass options keep connected equipment operational during routine maintenance or critical power module failure. Front-panel display offers full UPS condition and status reporting.


    PRODUCT SPECIFICATIONS
    Plug/Connector Type Hardwired
    Receptacle Type Hardwired
    Phase Three Phase
    Load Capacity (VA) 60 kVA
    Input Voltage
    • 120 V AC
    • 230 V AC
    Output Voltage
    • 120 V AC
    • 230 V AC
    Waveform Type Pure Sine Wave
    Network Management
    • SNMP Manageable
    • Telnet
    • SSH
    Backup/Run Time (Full Load) 3.90 Minute
    Backup/Run Time (Half Load) 8 Minute
    Form Factor Tower
    Height 79.13" (2010 mm)
    Width 23.62" (600 mm)
    Depth 43.31" (1100 mm)
    Weight (Approximate) 1520.99 lb (689910 g)
    Package Contents
    • SmartOnline SV60KM3P3B 60kVA Tower UPS
    • Pre-installed WEBCARDLX Network Interface
    • 3 x SV20PM 20kVA Power Modules
    • 3 x SVBM Battery Modules
    • Owner's Manual
    • DB9 Cabling
    Country of Origin China
    Environmentally Friendly Yes
    Environmental Compliance Restriction of Hazardous Substances (RoHS)
    Limited Warranty 1 Year
