Name: Tripp Lite by Eaton SmartOnline SVX SVX90KM3P5B 90kVA Tower UPS - SVX90KM3P5B - Double Conversion Online UPS, 230 V AC,380 V AC,400 V AC,415 V AC, Tower, Pure Sine Wave, 220 V AC,230 V AC,240 V AC,380 V AC,400 V AC,415 V AC, Hardwired, SmartOnline
Brand: Tripp Lite
SKU: SVX90KM3P5B
Price: 58879.0 CAD
Availability: OutOfStock

Tripp Lite by Eaton SmartOnline SVX SVX90KM3P5B 90kVA Tower UPS - SVX90KM3P5B - Double Conversion Online UPS, 230 V AC,380 V AC,400 V AC,415 V AC, Tower, Pure Sine Wave, 220 V AC,230 V AC,240 V AC,380 V AC,400 V AC,415 V AC, Hardwired, SmartOnline-UPSPLUSBATTERY

Price

Delivery across Canada

In stock, ready to ship
Inventory on the way

Quantity

[{"id":48160561168630,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"SVX90KM3P5B","requires_shipping":true,"taxable":true,"featured_image":{"id":43489145815286,"product_id":9010304614646,"position":1,"created_at":"2025-04-12T05:45:53-04:00","updated_at":"2025-04-12T05:45:53-04:00","alt":"Tripp Lite by Eaton SmartOnline SVX SVX90KM3P5B 90kVA Tower UPS - SVX90KM3P5B - Double Conversion Online UPS, 230 V AC,380 V AC,400 V AC,415 V AC, Tower, Pure Sine Wave, 220 V AC,230 V AC,240 V AC,380 V AC,400 V AC,415 V AC, Hardwired, SmartOnline-UPSPLUSBATTERY","width":900,"height":900,"src":"\/\/upsplusbattery.ca\/cdn\/shop\/files\/1045664054_5e3e28b0-83a4-46cf-b2c5-eb73c38adb3e.jpg?v=1744451153","variant_ids":[48160561168630]},"available":false,"name":"Tripp Lite by Eaton SmartOnline SVX SVX90KM3P5B 90kVA Tower UPS - SVX90KM3P5B - Double Conversion Online UPS, 230 V AC,380 V AC,400 V AC,415 V AC, Tower, Pure Sine Wave, 220 V AC,230 V AC,240 V AC,380 V AC,400 V AC,415 V AC, Hardwired, SmartOnline","public_title":null,"options":["Default Title"],"price":5887900,"weight":407241248,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Tripp Lite by Eaton SmartOnline SVX SVX90KM3P5B 90kVA Tower UPS - SVX90KM3P5B - Double Conversion Online UPS, 230 V AC,380 V AC,400 V AC,415 V AC, Tower, Pure Sine Wave, 220 V AC,230 V AC,240 V AC,380 V AC,400 V AC,415 V AC, Hardwired, SmartOnline-UPSPLUSBATTERY","id":35287271702774,"position":1,"preview_image":{"aspect_ratio":1.0,"height":900,"width":900,"src":"\/\/upsplusbattery.ca\/cdn\/shop\/files\/1045664054_5e3e28b0-83a4-46cf-b2c5-eb73c38adb3e.jpg?v=1744451153"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

Call us if you need a quote - particularly for out of stock items.

Product Features:

Brand: Tripp Lite by Eaton
Product Type: Double Conversion Online UPS
Manufacturer Part Number: SVX90KM3P5B
Input Voltage: 230 V AC,380 V AC,400 V AC,415 V AC
Form Factor: Tower
Waveform Type: Pure Sine Wave
Plug/Connector Type: Hardwired
Product Family: SmartOnline SVX
Backup/Run Time (Half Load): 8.80 Minute
Backup/Run Time (Full Load): 4.20 Minute
Load Capacity: 90 kVA

Tripp Lite's SVX90KM3P5B 90kVA/90kW SmartOnlineÂ® Medium-Frame UPS includes installed input, bypass and output breakers, a static transfer switch (STS) and 3 included 30kVA SVX30PM power modules. This system supports the addition of 1 additional user-installable SVX30PM power module to accommodate 90kW total capacity with N+1 fault-tolerance. Five internal battery modules are included to fully load internal battery compartments. Additional runtime is available using any number of compatible Â±240VDC external battery packs (sold separately).

Featuring a modular, scalable design with high-efficiency voltage and frequency independent/VFI operation, Tripp Lite's SVX Series SmartOnline UPS systems are ideal for the protection of a wide variety of critical IT systems. Scalable, modular configuration enables UPS capacity upgrades and hot-swap power supply maintenance without costly downtime. Over 95% efficient in standard online mode and over 99% efficient in optional economy mode enables reduced operating and cooling costs. Unity power factor configuration provides equal kVA and kW output ratings for up to 25% more wattage capacity than common 0.8 - 0.9 power factor competing designs. Network-grade sine-wave AC output with 1% output voltage regulation and less than 1.5% output total harmonic distortion. Advanced IGBT inverter with Digital Signal Processor (DSP) technology provides for less than 3% input total harmonic distortion (THDi) to support 1:1 generator sizing. Dual-input hardwire design enables operation from one or two input power sources for enhanced system availability. N+1 fault-tolerance is configurable anytime there is an "extra" SVX30PM 30kW power module installed beyond the minimum required quantity. Automatic and manual bypass options keep connected equipment operational during routine maintenance or critical power module failure.

Features

Tripp Lite's SVX90KM3P5B 90kVA/90kW SmartOnline UPS offers network-grade power protection in a highly configurable medium-frame modular, scalable form factor
Includes 3 SVX30PM 30kW power modules for 90kVA total capacity; Open slots for 1 additional SVX30PM 30kW power module enable enhanced N+1 redundancy
Included batteries support a full load of 90kW for 4.2 minutes and half load of 45kW for 8.8 minutes; Extended runtime is available with the addition of any number of supported external battery packs (sold separately)
Supports 220/380, 230/400 or 240/415V AC, 3-Phase Wye 4-Wire plus Earth Hardwire input and output wiring
Tested to CE for worldwide applications
Pre-installed WEBCARDLX network interface
Serial port enables unattended shutdown and UPS monitoring ability
Modular configuration with hot-swappable power modules enables easy and fast maintenance with zero downtime
Wide input voltage operating range enables full continuous online operation during brownouts as low as 120V (Ph-N) and overvoltages up to 276 (Ph-N)
Narrow output voltage operating range regulates output voltage within 1% of the selected 220/230/240 nominal output voltage in online, double-conversion mode
Over 95% efficient in online, double-conversion mode and over 99% efficient in optional economy-mode enables reduced operating and cooling costs
Less than 3% input Total Harmonic Distortion (THDi) prevents the need to oversize generator systems relative to UPS capacity
Dual hardwire input design enables operation from one or two input power sources
Front panel combination LCD/LED display offers full UPS condition and status reporting plus additional configuration options

Product Specifications:

Product Features:

Manufacturer:Eaton Corporation

Manufacturer Part Number:SVX90KM3P5B

Manufacturer Website Address:https://tripplite.eaton.com/

Brand Name:Tripp Lite by Eaton

Product Line:SmartOnline

Product Series:SVX

Product Model:SVX90KM3P5B

Product Name:SmartOnline SVX SVX90KM3P5B 90kVA Tower UPS

Marketing Information:

Tripp Lite's SVX90KM3P5B 90kVA/90kW SmartOnlineÂ® Medium-Frame UPS includes installed input, bypass and output breakers, a static transfer switch (STS) and 3 included 30kVA SVX30PM power modules. This system supports the addition of 1 additional user-installable SVX30PM power module to accommodate 90kW total capacity with N+1 fault-tolerance. Five internal battery modules are included to fully load internal battery compartments. Additional runtime is available using any number of compatible Â±240VDC external battery packs (sold separately).

Featuring a modular, scalable design with high-efficiency voltage and frequency independent/VFI operation, Tripp Lite's SVX Series SmartOnline UPS systems are ideal for the protection of a wide variety of critical IT systems. Scalable, modular configuration enables UPS capacity upgrades and hot-swap power supply maintenance without costly downtime. Over 95% efficient in standard online mode and over 99% efficient in optional economy mode enables reduced operating and cooling costs. Unity power factor configuration provides equal kVA and kW output ratings for up to 25% more wattage capacity than common 0.8 - 0.9 power factor competing designs. Network-grade sine-wave AC output with 1% output voltage regulation and less than 1.5% output total harmonic distortion. Advanced IGBT inverter with Digital Signal Processor (DSP) technology provides for less than 3% input total harmonic distortion (THDi) to support 1:1 generator sizing. Dual-input hardwire design enables operation from one or two input power sources for enhanced system availability. N+1 fault-tolerance is configurable anytime there is an "extra" SVX30PM 30kW power module installed beyond the minimum required quantity. Automatic and manual bypass options keep connected equipment operational during routine maintenance or critical power module failure.

Features

Tripp Lite's SVX90KM3P5B 90kVA/90kW SmartOnline UPS offers network-grade power protection in a highly configurable medium-frame modular, scalable form factor
Includes 3 SVX30PM 30kW power modules for 90kVA total capacity; Open slots for 1 additional SVX30PM 30kW power module enable enhanced N+1 redundancy
Included batteries support a full load of 90kW for 4.2 minutes and half load of 45kW for 8.8 minutes; Extended runtime is available with the addition of any number of supported external battery packs (sold separately)
Supports 220/380, 230/400 or 240/415V AC, 3-Phase Wye 4-Wire plus Earth Hardwire input and output wiring
Tested to CE for worldwide applications
Pre-installed WEBCARDLX network interface
Serial port enables unattended shutdown and UPS monitoring ability
Modular configuration with hot-swappable power modules enables easy and fast maintenance with zero downtime
Wide input voltage operating range enables full continuous online operation during brownouts as low as 120V (Ph-N) and overvoltages up to 276 (Ph-N)
Narrow output voltage operating range regulates output voltage within 1% of the selected 220/230/240 nominal output voltage in online, double-conversion mode
Over 95% efficient in online, double-conversion mode and over 99% efficient in optional economy-mode enables reduced operating and cooling costs
Less than 3% input Total Harmonic Distortion (THDi) prevents the need to oversize generator systems relative to UPS capacity
Dual hardwire input design enables operation from one or two input power sources
Front panel combination LCD/LED display offers full UPS condition and status reporting plus additional configuration options

PRODUCT SPECIFICATIONS
Plug/Connector Type	Hardwired
Receptacle Type	Hardwired
Phase	Three Phase
Application/Usage	IT Infrastructure
Load Capacity (VA)	90 kVA
Input Voltage	230 V AC 380 V AC 400 V AC 415 V AC
Output Voltage	220 V AC 230 V AC 240 V AC 380 V AC 400 V AC 415 V AC
Waveform Type	Pure Sine Wave
Network Management	SNMP Manageable
Backup/Run Time (Full Load)	4.20 Minute
Backup/Run Time (Half Load)	8.80 Minute
Form Factor	Tower
Height	79.13" (2009.90 mm)
Width	23.62" (599.90 mm)
Depth	43.30" (1099.80 mm)
Weight (Approximate)	1979 lb (897660 g)
Package Contents	SmartOnline SVX SVX90KM3P5B 90kVA Tower UPS 3 x SVX30PM 30kVA power modules 5 x SVXBM battery modules Pre-installed WEBCARDLX network interface Owner's manual
Country of Origin	China
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Limited Warranty	2 Year

Call us if more information required.
