Tripp Lite SmartPro 5000VA Tower/Rack-mountable Extended -Run UPS - SMX5000XLRT3U - Line-interactive UPS, 230 V AC, Rack/Tower, 3U, 220 V AC,230 V AC,240 V AC, Hardwired, SmartPro, 20 Minute, 8.50 Minute, 5 kVA/3.75 kW

Tripp Lite SmartPro 5000VA Tower/Rack-mountable Extended -Run UPS - SMX5000XLRT3U - Line-interactive UPS, 230 V AC, Rack/Tower, 3U, 220 V AC,230 V AC,240 V AC, Hardwired, SmartPro, 20 Minute, 8.50 Minute, 5 kVA/3.75 kW-UPSPLUSBATTERY

Tripp Lite SmartPro 5000VA Tower/Rack-mountable Extended -Run UPS - SMX5000XLRT3U - Line-interactive UPS, 230 V AC, Rack/Tower, 3U, 220 V AC,230 V AC,240 V AC, Hardwired, SmartPro, 20 Minute, 8.50 Minute, 5 kVA/3.75 kW

/
  • Delivery across Canada
  • In stock, ready to ship
  • Inventory on the way
Call us if you need a quote - particularly for out of stock items.
Product Features:
  • Brand: Tripp Lite by Eaton
  • Product Type: Line-interactive UPS
  • Manufacturer Part Number: SMX5000XLRT3U
  • Input Voltage: 230 V AC
  • Form Factor: Rack/Tower
  • Rack Height: 3U
  • Plug/Connector Type: Hardwired
  • Product Family: SmartPro
  • Backup/Run Time (Half Load): 20 Minute
  • Backup/Run Time (Full Load): 8.50 Minute
  • Load Capacity: 5 kVA/3.75 kW

    • Marketing Information: 5000VA line interactive UPS system for server, network and telecommunications equipment. 5kVA UPS with internal batteries installs in only 3 rack spaces with a depth of only 635mm / 25 inches. High 98% line-power efficiency rating reduces energy consumption and BTU heat output. Expandable battery runtime with optional BP48V24-2U (limit 1), BP48V60RT-3U (multi-pack compatible) and BP48V27-2US (multi-pack compatible) external battery packs. Uninterruptible Power Supply (UPS) switches to battery-derived AC output during power failures and extreme voltage variations. Line interactive Automatic Voltage Regulation (AVR) offers voltage boost during brownouts and voltage reduction during overvoltage conditions to maintain regulated 230v output over an input range of 170-282V. Supports hardwire input. Includes C19 and C13 output receptacles. Network-grade AC surge and noise suppression. Network management interfaces support communications via USB, DB9 serial and SNMPWEBCARD slot. Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all 3 network interfaces at once. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. 3-stage metered current monitoring and battery charge status LEDs. Utility power and voltage regulation LEDs. Audible alarm. Self-test. 4-post rackmount installation accessories included; 2-9USTAND tower kit and 2POSTRMKITHD two post rack mounting accessories available. Field-replaceable, hot-swappable internal batteries and external battery packs.
Product Specifications:
Product Features:
  • Manufacturer:Eaton Corporation
  • Manufacturer Part Number:SMX5000XLRT3U
  • Manufacturer Website Address:https://tripplite.eaton.com/
  • Brand Name:Tripp Lite by Eaton
  • Product Line:SmartPro
  • Product Name:SMX5000XLRT3U UPS System

    • Marketing Information:5000VA line interactive UPS system for server, network and telecommunications equipment. 5kVA UPS with internal batteries installs in only 3 rack spaces with a depth of only 635mm / 25 inches. High 98% line-power efficiency rating reduces energy consumption and BTU heat output. Expandable battery runtime with optional BP48V24-2U (limit 1), BP48V60RT-3U (multi-pack compatible) and BP48V27-2US (multi-pack compatible) external battery packs. Uninterruptible Power Supply (UPS) switches to battery-derived AC output during power failures and extreme voltage variations. Line interactive Automatic Voltage Regulation (AVR) offers voltage boost during brownouts and voltage reduction during overvoltage conditions to maintain regulated 230v output over an input range of 170-282V. Supports hardwire input. Includes C19 and C13 output receptacles. Network-grade AC surge and noise suppression. Network management interfaces support communications via USB, DB9 serial and SNMPWEBCARD slot. Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all 3 network interfaces at once. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. 3-stage metered current monitoring and battery charge status LEDs. Utility power and voltage regulation LEDs. Audible alarm. Self-test. 4-post rackmount installation accessories included; 2-9USTAND tower kit and 2POSTRMKITHD two post rack mounting accessories available. Field-replaceable, hot-swappable internal batteries and external battery packs.
    PRODUCT SPECIFICATIONS
    Plug/Connector Type Hardwired
    Receptacle Type
    • IEC 60320 C19
    • IEC 60320 C13
    Receptacle Detail
    • 3 x IEC 60320 C19
    • 8 x IEC 60320 C13
    Dataline Protection RJ-11
    Emergency Power OFF Yes
    Transfer Time 4 ms
    Load Capacity (VA) 5 kVA
    Load Capacity (Watt) 3.75 kW
    Input Voltage 230 V AC
    Output Voltage
    • 220 V AC
    • 230 V AC
    • 240 V AC
    Network Management SNMP Manageable
    Serial Port Yes
    USB Yes
    Backup/Run Time (Full Load) 8.50 Minute
    Backup/Run Time (Half Load) 20 Minute
    Typical Battery Recharge Time 4 Hour
    Hot Swappable Yes
    Height 5.20" (132.08 mm)
    Width 17.50" (444.50 mm)
    Depth 25" (635 mm)
    Rack Height 3U
    Form Factor Rack/Tower
    Weight (Approximate) 143 lb (64863.71 g)
    Package Contents
    • SMX5000XLRT3U UPS System
    • PowerAlert Software and Cabling
    • Mounting hardware for 4 post rackmount installation
    • Warranty information
    • Instruction manual
    Additional Information
    • Switches: Yes, includes 2 front panel-mounted push button switches for system enable, self-test and alarm cancel functions
    • Low voltage transfer to battery power: 170VAC (resets to line power as voltage increases to 179VAC)
    • High voltage transfer to battery power: 282V (resets to line power as voltage decreases to 274VAC)
    • Cold Start: Yes, inverter can be cold started to enable temporary AC output during a power failure
    • TVSS grounding: Includes back panel grounding point with thubscrew for dataline surge suppressors and other network accessories requiring a safe grounding point
    Certifications & Standards CE, GOST, SASO
    Software Included PowerAlert Software
    Country of Origin China
    Limited Warranty 2 Year

    Call us if more information required.
