About this UPS
APC by Schneider Electric Smart-UPS Ultra On-Line Lithium ion, 5KVA/5KW, 2U Rack/Tower, 208V
| UPC | 0731304435730 |
| 2U Rack/Tower - 1.50 Hour Recharge - 208 V Input - 208 V AC Output - Sine Wave - 2 x NEMA L6-20R, 2 x NEMA L6-30R | |
| General Information | |
|---|---|
| Manufacturer: | Schneider Electric SA |
| Manufacturer Part Number: | SRTL5KRM2UT |
| Manufacturer Website Address: | http://www.schneider-electric.com |
| Brand Name: | APC by Schneider Electric |
| Product Name: | Smart-UPS Ultra On-Line Lithium ion, 5KVA/5KW, 2U Rack/Tower, 208V |
| Marketing Information: | This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 5kVA on-line 2U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. The SRTL comes with NEMA L6-30P input, 2x NEMA L6-20R and 2x NEMA L6-30R outlets. The Smart-UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Serial Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 5-year warranty on the UPS and Lithium-ion battery. The SRTL delivers clean power with zero transfer time for critical or sensitive devices. Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications. |
| Packaged Quantity: | 4 Pack |
| Product Type: | Double Conversion Online UPS | Technical Information |
| Plug/Connector Type: | NEMA L6-30P |
| Receptacle Type: | NEMA L6-30P |
| Receptacle Detail: |
|
| Cord Length: | 10 ft | Power Description |
| Load Capacity (VA): | 4.90 kVA |
| Load Capacity (Watt): | 5 kW |
| Input Voltage: | 208 V |
| Output Voltage: | 208 V AC |
| Input Frequency: | 70 Hz |
| Output Frequency: | 60 Hz |
| Waveform Type: | Sine Wave |
| Surge Energy Rating: | 1260 J | Controls/Indicators |
| Status Indicators: | Multi-function LCD Status and Control Console | Interfaces/Ports |
| EPO Port: | Yes |
| USB (HID Compliant) Port: | No | Battery Information |
| DC System Voltage: | 180 V DC |
| Battery Chemistry: | Lithium Ion (Li-Ion) |
| Battery Energy: | 2592 kJ |
| Battery Life: | 10 Year |
| Typical Battery Recharge Time: | 1.50 Hour | Environmental Conditions |
| Maximum Operating Temperature: | 104 °F (40 °C) |
| Maximum Operating Elevation: | 10000 ft (3048000 mm) |
| Storage Relative Humidity: | 0% - 95% |
| Sound Emission (A-Weighted): | 55 dB(A) |
| Thermal Dissipation: | 1047 BTU/h | Physical Characteristics |
| Color Family: | Silver |
| Product Color: | Silver Gray |
| Height: | 3.39" (86 mm) |
| Width: | 17.01" (432 mm) |
| Depth: | 27.60" (701 mm) |
| Rack Height: | 2U |
| Form Factor: | Rack/Tower |
| Weight (Approximate): | 29.20 kg | Miscellaneous |
| Package Contents: |
|
| Certifications & Standards: | ENERGY STAR V2.0 (USA) |
| Energy Star: | Yes |
| Mercury Free: | Yes |
| REACH Declaration URL: | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=555124200&lang=en-us |
| EU RoHS Declaration URL: | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=555124200&lang=en-us |
| Environmental Profile Availability: | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP2311011_V1 |
| End of Life Manual Availability: | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI2311011_V1 |
| Energy Star URL: | https://www.energystar.gov/products/uninterruptible_power_supplies |
| WEEE Statement: | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Country of Origin: | Philippines |
| Environmentally Friendly: | Yes |
| Environmental Compliance: | Restriction of Hazardous Substances (RoHS) | Warranty |
| Limited Warranty: | 5 Year |
| Additional Warranty Information: | 5 years |
Technical specifications
Power
VA Rating
5000VA
Wattage
5000W
Topology
Online Double-Conversion
Waveform
Pure Sine Wave
Input
Input Voltage
208V
Output
Output Voltage
208V
Receptacles
2× NEMA L6-20R2× NEMA L6-30R
Features
Form Factor
Rackmount 2U
Connectivity
["USB""SNMP (via Network Management Card)""HTTP/Web Management"]
Extended Runtime Capable
true
Condition
New
Operating Temperature
0 to 40 °C (32 to 104 °F)
Dimensions
86 × 432 × 701 mm (3.39 × 17.01 × 27.60 in)
Weight
29.2kg
Manufacturer Warranty
5 years
Shipped across Canada
Shipped from our Canadian warehouse. See shipping policy for rates and timing.
Manufacturer-backed
New UPS units carry the full manufacturer warranty registered to you on receipt.
14 years in business
UPSPLUSBATTERY has supplied Canadian UPS systems since 2012.
Sizing & install help
Email your load profile — we'll spec the right UPS within one business hour.
Before you order
How do I know this UPS will run my equipment?
Add up the wattage draw of every device you'll plug in (servers, switches, monitors). The UPS's wattage rating — not VA — is the number that matters. Aim for the UPS to run at 60–70% of capacity at full load: this gives headroom for inrush current and a meaningful runtime margin. Email us your equipment list and we'll size the right UPS within one business hour.
What's covered by the warranty, and how long does it last?
New units carry the full manufacturer warranty registered to you on receipt. The manufacturer handles claims directly via their North American support channel. Refurbished units are covered by our own 1-year UPSPLUSBATTERY warranty handled in-house in Canada.
Can I extend runtime beyond what's shown above?
Many Smart-UPS-class models accept an external battery pack (XBP) connected to the rear battery port. If this UPS shows "Extended Runtime Capable: Yes" in the spec grid above, an XBP is supported. Compatible XBPs and the runtime gain they deliver vary by model — contact us if you don't see the right XBP in our catalogue.
