APC Smart-UPS SRT UPS Systems

About APC Smart-UPS SRT UPS Systems

APC Smart-UPS SRT: the online double-conversion line for critical loads

The APC Smart-UPS SRT (Smart-Runtime Technology) series is APC by Schneider Electric's premium online double-conversion UPS family. Unlike line-interactive models that switch to battery only when utility power fails, an online double-conversion UPS continuously rebuilds a clean pure sine wave output from rectified DC, fully isolating your equipment from sags, surges, frequency drift and noise. That makes the SRT line the right choice for servers, network closets, storage arrays, medical and lab equipment, and any load that cannot tolerate even a momentary transfer.

Within the APC lineup, SRT sits above the line-interactive Smart-UPS (SMT/SMX) and Back-UPS consumer tiers. It is built for IT and facilities buyers who need true online protection, hot-swappable batteries, scalable external runtime, and a network management slot for remote monitoring. The units in this collection range from 1000VA / 900W up to 10000VA / 10000W, in convertible tower and rackmount (2U, 3U, 4U and 5U+) chassis, with 120V, 208V and 230V output options to suit North American and international power.

Models in the SRT series

A representative selection from the range below. The full lineup includes 120V, 208V and 230V variants, IEC and L6-30 outlet configurations, and bundles with integrated step-down transformers — see the full range below.

Runtime figures are at the rated internal-battery configuration; all SRT units are extended-runtime capable with external battery packs. A dash means the figure is not published for that model.

How to choose

• Size by watts, not just VA. Add up the real power draw (watts) of everything you will plug in, then add 20–25% headroom. Across the SRT line the watt rating runs close to the VA rating (power factor near 0.9–1.0), so a 3000VA / 2700W unit safely supports roughly 2700W of load. Don't undersize against the VA number alone.
• Plan your runtime. Internal batteries give a few minutes — enough for a clean shutdown or a generator to start. If you need to ride through longer outages, every SRT model accepts external battery packs (extended-runtime capable), so choose a model whose battery family scales to the minutes you require.
• Topology. The entire SRT series is online double-conversion — the protection tier above line-interactive. If your equipment is sensitive to transfer time or dirty power, this is the line you want.
• Rack vs tower. Most SRT models ship in a convertible chassis that mounts in a rack (2U–5U+) or stands as a tower. Match the form factor and output voltage (120V / 208V / 230V) to your environment; 208V and step-down-transformer bundles are available for higher-density deployments.

Why the SRT series

• True online double-conversion with pure sine wave output — continuous isolation from power problems.
• Hot-swappable batteries and scalable external runtime across the range.
• Network-management options for remote monitoring and graceful shutdown.
• Wide capacity and voltage coverage — 1000VA to 10000VA, 120/208/230V, rack or tower.

Warranty, Canadian shipping & support

SRT units carry APC's standard manufacturer warranty (typically 3 years repair-or-replace on the electronics, with separate battery coverage; confirm the term on each product page). Every unit in this collection is genuine APC stock, shipped from our Canadian warehouse with Canadian support — no cross-border delays or surprise duties.

Already own an SRT and just need cells? See our APC UPS replacement battery collection for genuine APC RBC cartridges, and browse the full APC by Schneider Electric range for related models and accessories.

Frequently asked questions

What does "online double-conversion" mean, and why does the SRT use it?
The UPS continuously converts incoming AC to DC and back to a fresh AC sine wave, so your equipment always runs on conditioned power with zero transfer time when utility power fails. It's the highest protection tier and the reason SRT is chosen for servers and other sensitive loads.

How do I size an SRT for my equipment?
Total the wattage of your connected gear and add 20–25% headroom, then pick a model whose watt rating meets or exceeds that figure. Because SRT watt and VA ratings are close, the VA number alone is a reasonable first cut, but always confirm against watts.

Can I get more runtime than the internal battery provides?
Yes. Every SRT model is extended-runtime capable and accepts external battery packs, letting you scale from a few minutes to much longer hold-up times.

Do these mount in a rack or sit on the floor?
Most SRT models use a convertible chassis that racks at 2U–5U+ or stands as a tower, so you can deploy the same unit either way. Check the form factor on each product page.

Is this genuine APC, and is it stocked in Canada?
Yes — all SRT units are genuine APC by Schneider Electric, shipped from our Canadian warehouse with Canadian support.

UPSPLUSBATTERY is an authorized Canadian reseller of genuine APC by Schneider Electric UPS systems; APC, Smart-UPS, Schneider Electric and model names are trademarks of their respective owners.
