Eaton 9PX8KG2-L 8000 VA / 8000 W Rack/Tower 4U Online UPS, Lithium-Ion
Eaton 9PX8KG2-L 8000 VA / 8000 W Rack/Tower 4U Online UPS, Lithium-Ion
Items above $10000 are handled by quote so we can confirm availability, freight, and final pricing.
Available on order
Written reply within 1 business day, no obligation.
Supports extended runtime: add battery packs in your quote
Local pickup: available in the Montreal area, Quebec, by appointment. Call 438-881-3363 first.
- Prices in CAD. Shipping is available across Canada; see the shipping policy for rates and timing.
- New in box: manufacturer warranty applies
- Have a purchase order? Request a quote.
Questions? 438-881-3363 · Mon to Fri
About this UPS
The Eaton 9PX8KG2-L is a rackmount (4u) online double-conversion UPS with a Lithium-Ion battery for longer service life, wider operating-temperature range, and reduced maintenance compared to sealed lead-acid batteries. Designed for business-critical power protection, it delivers clean, regulated output to protect servers, network equipment, workstations, and other sensitive electronics from power disturbances, backed by Eaton's industry-leading warranty and service network.
Specifications
| Topology | Online Double-Conversion |
| Output Waveform | Pure Sine Wave |
| Output Voltage | 208 VAC |
| Form Factor | Rackmount (4U) |
| Communications | USB, Serial |
| Warranty | 5 Years Limited |
| Battery Chemistry | Lithium-Ion |
| Weight | 64.8 kg (142.86 lb) |
| Manufacturer Part Number | 9PX8KG2-L |
Technical specifications
Setup checklist: after you receive your UPS →
How long it'll keep your equipment up.
Manufacturer-specified runtime at typical loads. Real-world figures depend on battery age, ambient temperature, and load profile.
Need more runtime? This UPS accepts external battery packs (XBPs). Contact us about XBP options →
Compare with alternatives
The 9PX8KG2-L side by side with UPS from other makers.
-
Xtreme Power Conversion
Xtreme Power P91-10KB3 10000 VA / 10000 W Online UPS, 208/230 V
Compared with 9PX8KG2-L Spec 9PX8KG2-L Xtreme Power Capacity 8000 VA / 8000 W 10000 VA / 10000 W Topology Online Double-Conversion Online Double-Conversion Form Tower/Rack Convertible, 4U Tower/Rack Convertible, 4U Input plug Hardwired Hardwired Outlets 4 × NEMA L6-30R, 1 × Hardwire terminal block 1 × Hardwire terminal block, 1 × NEMA L6-30R, 2 × NEMA L6-20R Runtime, half load 22 min 7 min Differences
- Three pieces: UPS module, 2U battery pack, bypass module
- 3 battery-backed outlets instead of 4
- Network card not included
Price confirmed by quote Request a quote -
Compared with 9PX8KG2-L Spec 9PX8KG2-L Delta Capacity 8000 VA / 8000 W 8000 VA / 8000 W Topology Online Double-Conversion Online Double-Conversion Form Tower/Rack Convertible, 4U Tower/Rack Convertible, 5U Input plug Hardwired Hardwired Outlets 4 × NEMA L6-30R, 1 × Hardwire terminal block 2 × NEMA L6-20R, 2 × NEMA L6-30R, 1 × NEMA L6-30R, 1 × Hardwire terminal block (5 on battery) Runtime, half load 22 min Not stated Differences
- Input 208 V only; this model also accepts 240 V
- Takes 5U of rack space instead of 4U
- Network card not included
Price confirmed by quote Request a quote -
Compared with 9PX8KG2-L Spec 9PX8KG2-L Delta Capacity 8000 VA / 8000 W 10000 VA / 10000 W Topology Online Double-Conversion Online Double-Conversion Form Tower/Rack Convertible, 4U Tower/Rack Convertible, 5U Input plug Hardwired Hardwired Outlets 4 × NEMA L6-30R, 1 × Hardwire terminal block 2 × NEMA L6-20R, 2 × NEMA L6-30R, 1 × NEMA L6-30R, 1 × Hardwire terminal block (5 on battery) Runtime, half load 22 min Not stated Differences
- Input 208 V only; this model also accepts 240 V
- Takes 5U of rack space instead of 4U
- Network card not included
- Larger unit: 10000 W instead of 8000 W
Price confirmed by quote Request a quote
Check outlets and the runtime your load needs before ordering. Questions? Call 438-881-3363 or ask for a quote.
Works with this UPS
Only accessories the manufacturer lists for this model.
Questions before you buy
How do I know this UPS will run my equipment?
Add up the wattage draw of every device you'll plug in (servers, switches, monitors). The UPS's wattage rating (not VA) is the number that matters. Aim for the UPS to run at 60 to 70% of capacity at full load: this gives headroom for inrush current and a meaningful runtime margin. Email us your equipment list; we'll respond within one business day with sizing guidance.
What's covered by the warranty, and how long does it last?
New units carry the warranty coverage stated by the manufacturer; see the product listing or manufacturer documentation for the applicable terms. Refurbished units are covered by the 1-year UPSPLUSBATTERY warranty handled in Canada.
Can I extend runtime beyond what's shown above?
Many Smart-UPS-class models accept an external battery pack (XBP) connected to the rear battery port. If this UPS shows "Extended Runtime Capable: Yes" in the spec grid above, an XBP is supported. Compatible XBPs and the runtime gain they deliver vary by model; contact us if you don't see the right XBP in our catalogue.
