UPS External Battery Cabinets

Match the cabinet to the UPS

An external battery cabinet adds battery capacity to a compatible UPS, or supplies the battery system required by a UPS module. Cabinets are selected by model, battery voltage and connection requirements. A matching brand or kVA label alone is not enough to establish compatibility.

Powervar Sinergy III cabinet selection

• 17888-02R / E024-12: 24 VDC cabinet for compatible ACDEF700-11 and ACDEF1000-11 systems.
• 17888-03R / E036-12: 36 VDC cabinet for compatible ACDEF1500-11 systems.
• 17888-04R / E048-12: 48 VDC cabinet for compatible ACDEF2000-11 and ACDEF2000-22 systems.
• 17888-05R / E072-12: 72 VDC cabinet for compatible ACDEF3000-11 and ACDEF3000-22 systems.
• 17888-01R / E240-22-A: 240 VDC cabinet for compatible ACDEF6000-22-1 and ACDEF6000-22-4 systems.

Check the full model suffix and current manufacturer documentation before ordering. Product pages provide the cabinet model and supporting information.

360PQ 6 kVA battery cabinet

PL-BATT-6kVA is the external battery cabinet for the 360PQ PL-H060-02. Confirm the current cabinet revision and battery configuration against your UPS. The PL-H060-02 UPS module requires an external battery cabinet, sold separately.

Check your runtime requirement

UPS power capacity and battery runtime are different specifications. Provide the connected load and desired backup time when checking a cabinet selection. Also confirm cabinet dimensions, cable requirements and delivery arrangements.

Compare 360PQ UPS systems or Powervar UPS systems, or send your UPS model to UPSPLUSBATTERY for a compatibility check.
