In stockEaton
· 5P750
Eaton 5P750 750 VA / 600 W Line-Interactive UPS
- Power
- 750 VA / 600 W
- Form
- Tower
- Outlets
- 8× NEMA 5-15R
$690.99
About this UPS
Product Features:
- Brand: Tripp Lite
- Product Type: Line-interactive UPS
- Manufacturer Part Number: SMART750XLA
- Input Voltage: 120 V AC
- Form Factor: Tower
- Plug/Connector Type: NEMA 5-15P
- Backup/Run Time (Half Load): 27 Minute
- Backup/Run Time (Full Load): 10 Minute
- Load Capacity: 750 VA/500 W
Marketing Information:
750VA line-interactive tower UPS system for server, networking and telecommunications equipment. Supports extended runtime with optional BP24V28-2U and BP24V70-3U external battery packs. Compatible with 120V, 110V or 100V nominal voltage at 60Hz. Switches to battery-derived AC output during power failures and extreme voltage variations. Line-interactive automatic voltage regulation (AVR) provides voltage boost during brownouts and voltage cut during overvoltages to maintain regulated output during brownouts and overvoltages. Includes NEMA 5-15P input plug and 8 NEMA 5-15R output receptacles. Network-grade AC surge and noise suppression. Network management via USB port, DB9 serial port and SNMPWEBCARD slot. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Supports detailed monitoring of equipment load levels, self-test data and utility power conditions via all 3 network interfaces at once. Includes PowerAlert monitoring softwa
Product Specifications:
-
Plug/Connector Type: NEMA 5-15PReceptacle Type: NEMA 5-15RReceptacle Detail: 8 x NEMA 5-15RTransfer Time: 4 msLoad Capacity: 750 VA/500 WInput Voltage: 120 V ACOutput Voltage: 120 V ACBackup/Run Time (Full Load): 10 MinuteTypical Battery Recharge Time: 4.50 HourHeight: 10.10" (256.54 mm)Width: 6.70" (170.18 mm)Depth: 13.80" (350.52 mm)Form Factor: TowerWeight (Approximate): 15.38 kgPackage Contents:
- SMART750XLA 750VA Tower UPS
- SMART 750XLa UPS System
- PowerAlert Software CD-Rom
- USB and serial cabling
- User manual with warranty information
Technical specifications
Power
VA Rating
750VA
Wattage
500W
Topology
Line-Interactive
Waveform
Pure Sine Wave
Input
Input Voltage
120V
Input Plug
NEMA 5-15P (standard 15A)
Input Phase
Single-phase
Output
Output Voltage
120V
Receptacles
8× NEMA 5-15R
Features
Form Factor
Tower
Connectivity
USBRS-232 Serial
Network Card Installed
No
Extended Runtime Capable
Yes
Condition
New
Dimensions
257 × 170 × 351 mm (10.10 × 6.70 × 13.80 in)
Weight
15.38kg
Certifications
CSA (Canada)NOM (Mexico)UL 1778
Manufacturer Warranty
3 years
Setup checklist: after you receive your UPS →
Backup runtime
How long it'll keep your equipment up.
Manufacturer-specified runtime at typical loads. Real-world figures depend on battery age, ambient temperature, and load profile.
Half load (250 W)
21 min
Full load (500 W)
10 min
Need more runtime? This UPS accepts external battery packs (XBPs). Contact us about XBP options →
Available now
The manufacturer no longer makes the SMART750XLA. These UPS are sold today; each card compares one with the discontinued model.
-
Xtreme Power Conversion
Xtreme Power T91-700 700 VA / 700 W Online UPS, 120 V
Compared with SMART750XLA Spec SMART750XLA Xtreme Power Capacity 750 VA / 500 W 700 VA / 700 W Topology Line-Interactive Online Double-Conversion Form Tower Tower Input plug NEMA 5-15P NEMA 5-15P Outlets 8 × NEMA 5-15R 6 × NEMA 5-15R Runtime, half load 21 min 16 min Differences
- 6 battery-backed outlets instead of 8
- No external battery option
- Lower VA rating: 700 VA instead of 750 VA
- Online double-conversion, a step up from line-interactive
$958.94
Check outlets and the runtime your load needs before ordering. Questions? Call 438-881-3363 or ask for a quote.
Discontinued by the manufacturer
Available now
The manufacturer no longer makes the SMART750XLA. These UPS are sold today; each card compares one with the discontinued model.
Questions? Call 438-881-3363 or ask for a quote.
Shipped across Canada
Shipping is available across Canada. See the shipping policy for rates and timing.
Manufacturer-backed
New UPS units carry the warranty coverage stated by the manufacturer. See the product listing or manufacturer documentation for the applicable terms.
In business since 2012
UPSPLUSBATTERY has supplied Canadian UPS systems since 2012.
Sizing & install help
Email your load profile and we'll spec the right UPS within one business day.
Replacement batteries that fit this exact UPS
A line-interactive UPS typically needs new batteries every 3 to 5 years. Matching replacement cartridges are listed by UPS model; confirm the exact model before ordering.
Bookmark this page
before you need it.
Questions before you buy
How do I know this UPS will run my equipment?
Add up the wattage draw of every device you'll plug in (servers, switches, monitors). The UPS's wattage rating (not VA) is the number that matters. Aim for the UPS to run at 60 to 70% of capacity at full load: this gives headroom for inrush current and a meaningful runtime margin. Email us your equipment list; we'll respond within one business day with sizing guidance.
What's covered by the warranty, and how long does it last?
New units carry the warranty coverage stated by the manufacturer; see the product listing or manufacturer documentation for the applicable terms. Refurbished units are covered by the 1-year UPSPLUSBATTERY warranty handled in Canada.
Can I extend runtime beyond what's shown above?
Many Smart-UPS-class models accept an external battery pack (XBP) connected to the rear battery port. If this UPS shows "Extended Runtime Capable: Yes" in the spec grid above, an XBP is supported. Compatible XBPs and the runtime gain they deliver vary by model; contact us if you don't see the right XBP in our catalogue.
