About this UPS
Product Features:
- Brand: Tripp Lite by Eaton
- Product Type: Line-interactive UPS
- Manufacturer Part Number: SMART1050SLT
- Input Voltage: 100 V AC,110 V AC,120 V AC
- Form Factor: Tower
- Waveform Type: Sine Wave
- Plug/Connector Type: NEMA 5-15P
- Product Family: SmartPro
- Backup/Run Time (Half Load): 19 Minute
- Backup/Run Time (Full Load): 7 Minute
- Load Capacity: 1.05 kVA/650 W
- Provides fully regulated sine wave AC output for point-of-sale applications, VoIP systems and small business networks
- Audible alarm signals loss of utility power, low battery or overload
- 8 NEMA 5-15R outlets
- 6 ft. power cord with 120V NEMA 5-15P input
- 690-joule surge suppression rating
- Supports half load up to 19 min. and full load up to 7 min.
- Internal batteries designed for hot-swap field replacement
- 95% line-power efficiency rating saves money in energy costs
- Cold-start capability enables turn-on in battery mode during blackouts
- Maintains selectable 100V, 110V or 120V nominal output over input range of 83V-145V without using battery power
- Removes electromagnetic and radio frequency interference that can disrupt or damage equipment's performance
- Front-panel LEDs signal indicate line power, battery power, overload, voltage regulation and battery status
- Compatible with Tripp Lite UPS management card options WEBCARDLX, SNMPWEBCARD and RELAYIOCARD
- USB & Serial ports enable data-saving unattended shutdown when used with Tripp Lite's PowerAlert software, available via FREE download from www.tripplite.com/poweralert
- Protect against power surges over telephone/DSL or network Ethernet lines
Marketing Information:
Protects Mission-Critical Equipment
Reliable Battery Backup
Automatic Voltage Regulation (AVR)
EMI/RFI Line Noise Filtering
LED Indicators
Network Management Cards
Communication Ports
Telephone/Network Jacks
Product Specifications:
Product Features:
| PRODUCT SPECIFICATIONS | |
|---|---|
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 8 x NEMA 5-15R |
| Cord Length | 6 ft (1.83 m) |
| Load Capacity (VA) | 1.05 kVA |
| Load Capacity (Watt) | 650 W |
| Input Voltage |
|
| Output Voltage |
|
| Waveform Type | Sine Wave |
| Network Management | SNMP Manageable |
| Alarm |
|
| Status Indicators | Includes 14 front panel LEDs to indicate line / battery power status, over / under voltage correction, battery charge level (4 LEDs), load percentage (4 LEDs), overload and replace battery. Also includes 1 rear panel site wiring fault indicator. |
| USB | Yes |
| Total Number of Expansion Slots | 1 |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 7 Minute |
| Backup/Run Time (Half Load) | 19 Minute |
| Battery Life | 6 Year |
| Typical Battery Recharge Time | 4 Hour |
| Hot Swappable | Yes |
| Maximum Operating Temperature | 104 °F (40 °C) |
| Height | 10.20" (259.08 mm) |
| Width | 6.80" (172.72 mm) |
| Depth | 13.20" (335.28 mm) |
| Form Factor | Tower |
| Weight (Approximate) | 43 lb (19504.47 g) |
| Package Contents |
|
| Additional Information |
|
| Certifications & Standards | UL1778 (USA), cUL (Canada), FCC Class B (emissions), IEC 1000-4-2 Level 3 (Electrostatic Discharge), IEC 1000-4-4 Level 2 (Fast Transient / Burst), IEC 1000-4-5 Level 3 (Lightning Surge), Conforms to IEEE 587 / ANSI C62.41 specifications |
| Country of Origin | China |
| Limited Warranty | 2 Year |
Technical specifications
Power
VA Rating
1050VA
Wattage
650W
Topology
Line-Interactive
Waveform
Pure Sine Wave
Input
Input Voltage
120V
Input Plug
NEMA 5-15P (standard 15A)
Input Phase
Single-phase
Output
Output Voltage
100V
Receptacles
8× NEMA 5-15R
Features
Form Factor
Tower
Connectivity
USBSNMP (via Network Management Card)HTTP/Web Management
Network Card Installed
No
Extended Runtime Capable
No
Condition
New
Operating Temperature
0 to 40 °C (32 to 104 °F)
Dimensions
259 × 173 × 335 mm (10.20 × 6.80 × 13.20 in)
Weight
19.5kg
Certifications
CSA (Canada)NOM (Mexico)UL 1778
Manufacturer Warranty
2 years
Setup checklist: after you receive your UPS →
Backup runtime
How long it'll keep your equipment up.
Manufacturer-specified runtime at typical loads. Real-world figures depend on battery age, ambient temperature, and load profile.
Half load (325 W)
19 min
Full load (650 W)
7 min
Compare with alternatives
The SMART1050SLT side by side with UPS from other makers.
-
Xtreme Power Conversion
Xtreme Power P80-800 800 VA / 720 W Line-Interactive UPS, 120 V
Compared with SMART1050SLT Spec SMART1050SLT Xtreme Power Capacity 1050 VA / 650 W 800 VA / 720 W Topology Line-Interactive Line-Interactive Form Tower Tower/Rack Convertible, 2U Input plug NEMA 5-15P NEMA 5-15P Outlets 8 × NEMA 5-15R 8 × NEMA 5-15R Runtime, half load 19 min 11 min Differences
- Lower VA rating: 800 VA instead of 1050 VA
$1,068.18 -
Xtreme Power Conversion
Xtreme Power T91-700 700 VA / 700 W Online UPS, 120 V
Compared with SMART1050SLT Spec SMART1050SLT Xtreme Power Capacity 1050 VA / 650 W 700 VA / 700 W Topology Line-Interactive Online Double-Conversion Form Tower Tower Input plug NEMA 5-15P NEMA 5-15P Outlets 8 × NEMA 5-15R 6 × NEMA 5-15R Runtime, half load 19 min 16 min Differences
- 6 battery-backed outlets instead of 8
- Lower VA rating: 700 VA instead of 1050 VA
- Online double-conversion, a step up from line-interactive
$958.94 -
Compared with SMART1050SLT Spec SMART1050SLT Delta Capacity 1050 VA / 650 W 1000 VA / 900 W Topology Line-Interactive Online Double-Conversion Form Tower Tower/Rack Convertible, 2U Input plug NEMA 5-15P NEMA 5-15P Outlets 8 × NEMA 5-15R 8 × NEMA 5-15R Runtime, half load 19 min 10 min Differences
- Lower VA rating: 1000 VA instead of 1050 VA
- Online double-conversion, a step up from line-interactive
- Larger unit: 900 W instead of 650 W
$1,777.99
Check outlets and the runtime your load needs before ordering. Questions? Call 438-881-3363 or ask for a quote.
Shipped across Canada
Shipping is available across Canada. See the shipping policy for rates and timing.
Manufacturer-backed
New UPS units carry the warranty coverage stated by the manufacturer. See the product listing or manufacturer documentation for the applicable terms.
In business since 2012
UPSPLUSBATTERY has supplied Canadian UPS systems since 2012.
Sizing & install help
Email your load profile and we'll spec the right UPS within one business day.
Replacement batteries that fit this exact UPS
A line-interactive UPS typically needs new batteries every 3 to 5 years. Matching replacement cartridges are listed by UPS model; confirm the exact model before ordering.
Bookmark this page
before you need it.
Questions before you buy
How do I know this UPS will run my equipment?
Add up the wattage draw of every device you'll plug in (servers, switches, monitors). The UPS's wattage rating (not VA) is the number that matters. Aim for the UPS to run at 60 to 70% of capacity at full load: this gives headroom for inrush current and a meaningful runtime margin. Email us your equipment list; we'll respond within one business day with sizing guidance.
What's covered by the warranty, and how long does it last?
New units carry the warranty coverage stated by the manufacturer; see the product listing or manufacturer documentation for the applicable terms. Refurbished units are covered by the 1-year UPSPLUSBATTERY warranty handled in Canada.
Can I extend runtime beyond what's shown above?
Many Smart-UPS-class models accept an external battery pack (XBP) connected to the rear battery port. If this UPS shows "Extended Runtime Capable: Yes" in the spec grid above, an XBP is supported. Compatible XBPs and the runtime gain they deliver vary by model; contact us if you don't see the right XBP in our catalogue.
