| UPC | 0743172082527 |
| 6U Rack/Tower - 7 Minute Stand-by - 230 V AC Input - 120 V AC, 208 V AC, 240 V AC, 100 V AC, 200 V AC, 115 V AC, 230 V AC, 127 V AC, 220 V AC Output - True Sine Wave - Serial Port - USB - 6 x NEMA 5-20R, 1 x NEMA L6-30R, 1 x NEMA L14-30R - SNMP/Web, Network-M3 Card | |
| General Information | |
|---|---|
| Manufacturer: | Eaton Corporation |
| Manufacturer Part Number: | 9PX3K3UNP1 |
| Manufacturer Website Address: | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Brand Name: | Eaton |
| Product Series: | 9PX |
| Product Model: | 9PX3K3UNP1 |
| Product Name: | 9PX3K3UNP1 3000VA Rack/Tower UPS |
| Marketing Information: |
The Eaton 9PX is a proven, best-in-class online double-conversion rackmount/tower UPS. The 9PX UPS features ABM technology, which extends battery service life up to 50 percent, and offers flexibility in battery types with nine models offering lithium-ion batteries. Select 9PX UPS models are bundled with theEaton Gigabit Network card, the first in the industry to comply with both UL and IEC cybersecurity standards. To complete your backup power solution, pair your 9PX with the Brightlayer Data Centers suitefor seamless management of your connected equipment. Applications: IT, edge networks, medical/healthcare, universities, K-12, industrial automation, harsh electrical environments. |
| Product Type: | Double Conversion Online UPS | Technical Information |
| Plug/Connector Type: | NEMA L6-30P |
| Receptacle Type: |
|
| Receptacle Detail: |
|
| Cord Length: | 6 ft |
| Application/Usage: |
|
Power Description |
| Load Capacity (VA): | 3 kVA |
| Load Capacity (Watt): | 3 kW |
| Input Voltage: | 230 V AC |
| Output Voltage: |
|
| Input Frequency: |
|
| Output Frequency: |
|
| Waveform Type: | True Sine Wave |
| Output Power Factor: | 1 | Management |
| Network Management: |
|
Interfaces/Ports |
| Serial Port: | Yes |
| Network (RJ-45): | Yes |
| USB: | Yes |
| Number of USB Ports: | 1 | Battery Information |
| Battery Characteristics: | Sealed |
| Battery Chemistry: | Lead Acid |
| Backup/Run Time (Full Load): | 7 Minute |
| Backup/Run Time (Half Load): | 19 Minute |
| Hot Swappable: | Yes |
| Replaceable Battery: | Yes | Physical Characteristics |
| Height: | 10.20" (259.08 mm) |
| Width: | 17.30" (439.42 mm) |
| Depth: | 28.40" (721.36 mm) |
| Rack Height: | 6U |
| Form Factor: | Rack/Tower |
| Weight (Approximate): | 92.08 kg | Miscellaneous |
| Package Contents: |
|
| Certifications & Standards: |
|
| Energy Star: | Yes | Warranty |
| Limited Warranty: | 3 Year |
Call us if more information required.
