About this UPS
Product Features:
- Brand: Tripp Lite by Eaton
- Product Type: Line-interactive UPS
- Manufacturer Part Number: AVRX750UA
- Input Voltage: 230 V AC
- Form Factor: Ultra-compact Desktop/Tower/Wall Mount
- Waveform Type: Sine Wave
- Plug/Connector Type: IEC 60320 C14
- Backup/Run Time (Half Load): 8.60 Minute
- Backup/Run Time (Full Load): 2.40 Minute
- Load Capacity: 750 VA/450 W
Marketing Information: Desktop UPS offers complete power protection for small network applications, including home offices, security systems and digital signage.
Features
750VA/450W/230V Battery Backup for Home and Office Workstations
The ultra-compact line-interactive AVRX750UA UPS system with AVR provides reliable battery backup and AC power protection against blackouts, brownouts, overvoltages, surges and line noise that can damage valuable electronics or destroy data. The 230V battery backup is ideal protection for desktop workstations and other essential business and small-network office equipment. This UPS system is also recommended for digital signage and home networking applications, such as Wi-Fi routers and modems, home offices, security systems and home theaters.
Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages
Backup support allows you to work through short power failures and gives you enough time to safely save files and shut down your system in case of a prolonged blackout. Backup time varies according to load, but internal battery should keep a half load (225W) powered as long as 8.6 minutes and a full load (450W) up to 2.4 minutes. During normal operation, incoming utility power keeps the hot-swappable internal battery fully charged, so backup power will always be available.
6 C13 Outlets Protect Your Connected Components
Three C13 outlets provide battery backup, 320 joules of surge protection and voltage regulation for your computer, monitor and other crucial components. Three others provide only surge and voltage protection for equipment less vital, such as printers and scanners. Included outlet adapters convert two C13 outlets to 10A Australia/New Zealand-compatible outlets. Dual network data line jacks protect a wired peripheral from dangerous surges on a single dial-up or DSL connection.
Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions
AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts and overvoltages. The AVRX750UA can correct brownouts as low as 159V and overvoltages as high as 282V back to nominal 230V power continuously, all while keeping the battery fully charged and ready to take over in case of power failure.
Premium Protection from EMI/RFI Line Noise Helps Your Equipment Perform Better
This UPS system filters out disruptive electromagnetic and radio frequency interference that can inflict hardware damage or data loss. This EMI/RFI filtering also helps your connected components perform
Designed for High Efficiency to Help You Save Money and Protect the Environment
A >95% efficiency rating reduces BTU emissions, energy consumption and, ultimately, your energy costs.
Product Specifications:
Product Features:
| PRODUCT SPECIFICATIONS | |
|---|---|
| AVR | Yes |
| Plug/Connector Type | IEC 60320 C14 |
| Receptacle Type | IEC 60320 C13 |
| Receptacle Detail | 6 x IEC 60320 C13 |
| Transfer Time | 2.40 ms |
| EMI/RFI Noise Filter | Yes |
| Phase | Single Phase |
| Application/Usage |
|
| Load Capacity (VA) | 750 VA |
| Load Capacity (Watt) | 450 W |
| Input Voltage | 230 V AC |
| Output Voltage |
|
| Output Frequency | 60 Hz |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 320 J |
| Alarm |
|
| Status Indicators |
LEDs:
|
| USB (HID Compliant) Port | Yes |
| DC System Voltage | 12 V DC |
| Battery Characteristics | Valve-regulated |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 2.40 Minute |
| Backup/Run Time (Half Load) | 8.60 Minute |
| Hot Swappable | Yes |
| Replaceable Battery | Yes |
| Maximum Operating Temperature | 104 °F (40 °C) |
| Storage Temperature | 5 °F (-15 °C) - 122 °F (50 °C) |
| Thermal Dissipation | 20 BTU/h |
| Height | 4.02" (102 mm) |
| Width | 12.01" (305 mm) |
| Depth | 7.01" (178 mm) |
| Form Factor | Ultra-compact Desktop/Tower/Wall Mount |
| Weight (Approximate) | 14.31 lb (6490 g) |
| Package Contents |
|
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Limited Warranty | 2 Year |
Technical specifications
Power
VA Rating
750VA
Wattage
450W
Topology
Line-Interactive
Waveform
Pure Sine Wave
Input
Input Voltage
240V
Output
Output Voltage
230V
Receptacles
6× IEC 60320 C13
Features
Form Factor
Tower
Connectivity
["USB""HTTP/Web Management"]
Condition
New
Operating Temperature
0 to 40 °C (32 to 104 °F)
Dimensions
102 × 305 × 178 mm (4.02 × 12.01 × 7.01 in)
Weight
6.49kg
Manufacturer Warranty
2 years
Backup runtime
How long it'll keep your equipment up.
Manufacturer-specified runtime at typical loads. Real-world figures depend on battery age, ambient temperature, and load profile.
Half load (225 W)
10.0 min
Full load (450 W)
2.4 min
W
Estimated runtime
—min
Estimate based on manufacturer-specified runtime curve. Real-world runtime varies with battery age, ambient temperature, and load profile.
Shipped across Canada
Shipped from our Canadian warehouse. See shipping policy for rates and timing.
Manufacturer-backed
New UPS units carry the full manufacturer warranty registered to you on receipt.
14 years in business
UPSPLUSBATTERY has supplied Canadian UPS systems since 2012.
Sizing & install help
Email your load profile — we'll spec the right UPS within one business hour.
Before you order
How do I know this UPS will run my equipment?
Add up the wattage draw of every device you'll plug in (servers, switches, monitors). The UPS's wattage rating — not VA — is the number that matters. Aim for the UPS to run at 60–70% of capacity at full load: this gives headroom for inrush current and a meaningful runtime margin. Email us your equipment list and we'll size the right UPS within one business hour.
What's covered by the warranty, and how long does it last?
New units carry the full manufacturer warranty registered to you on receipt. The manufacturer handles claims directly via their North American support channel. Refurbished units are covered by our own 1-year UPSPLUSBATTERY warranty handled in-house in Canada.
Can I extend runtime beyond what's shown above?
Many Smart-UPS-class models accept an external battery pack (XBP) connected to the rear battery port. If this UPS shows "Extended Runtime Capable: Yes" in the spec grid above, an XBP is supported. Compatible XBPs and the runtime gain they deliver vary by model — contact us if you don't see the right XBP in our catalogue.
