About this UPS
- Brand: Tripp Lite by Eaton
- Product Type: Standby UPS
- Manufacturer Part Number: ECO850LCD
- Input Voltage: 120 V AC
- Form Factor: Ultra-compact Desktop/Tower/Wall Mount
- Waveform Type: Pulse-width Modulated Sine Wave
- Plug/Connector Type: NEMA 5-15P
- Product Family: ECO
- Backup/Run Time (Half Load): 9 Minute
- Backup/Run Time (Full Load): 2.30 Minute
- Load Capacity: 850 VA/425 W
Marketing Information:
Ultra-compact, green UPS system is the ideal green solution for complete protection against blackouts, brownouts and power surges. Its 850VA/425-watt power handling capacity supports entry-level PC systems for up to 45 minutes during blackouts. With a power efficiency rating of 99 percent, this UPS offers energy savings plus cooler operation by limiting UPS power consumption. Interactive LCD screen displays operating conditions and lets you change settings. Design also features six battery-supported outlets for computer and peripherals plus six surge suppression-only outlets for accessories not requiring battery support. Four of the surge-only outlets are ECO outlets that can be configured to automatically power off unused computer accessories. Built-in, single-line, tel/DSL (RJ11) jacks protect a modem, fax machine or phone. One USB port (USB cable included) plus free PowerAlert software enables unattended system shutdown without data loss in the case of an extended power failure.
| PRODUCT SPECIFICATIONS | |
|---|---|
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 12 x NEMA 5-15R |
| Number of Battery & Surge Outlets | 6 |
| Number of Surge-only Outlets | 6 |
| Dataline Protection | RJ-11 |
| Protection Type |
|
| Transfer Time | 6 ms |
| EMI/RFI Noise Filter | Yes |
| Phase | Single Phase |
| Application/Usage |
|
| Load Capacity (VA) | 850 VA |
| Load Capacity (Watt) | 425 W |
| Input Voltage | 120 V AC |
| Input Current | 10 A |
| Output Voltage |
|
| Input Frequency | 60 Hz |
| Output Frequency | 60 Hz |
| Waveform Type | Pulse-width Modulated Sine Wave |
| Surge Energy Rating | 316 J |
| Alarm |
|
| Status Indicators | Touchscreen LCD reports operating mode, input/output voltage, input/output frequency and load capacity |
| USB | Yes |
| USB (HID Compliant) Port | Yes |
| DC System Voltage | 12 V DC |
| Backup/Run Time (Full Load) | 2.30 Minute |
| Backup/Run Time (Half Load) | 9 Minute |
| Typical Battery Recharge Time | 8 Hour |
| Replaceable Battery | Yes |
| Maximum Operating Temperature | 104 °F (40 °C) |
| Storage Temperature | 5 °F (-15 °C) - 113 °F (45 °C) |
| Color Family | Black |
| Product Color | Black |
| Height | 3.50" (88.90 mm) |
| Width | 5.12" (130.05 mm) |
| Depth | 12.20" (309.88 mm) |
| Form Factor | Ultra-compact Desktop/Tower/Wall Mount |
| Weight (Approximate) | 6.81 lb (3090 g) |
| Package Contents |
|
| Certifications & Standards | UL Listed Certification |
| Recycled | No |
| Assembly Required | No |
| Energy Star | Yes |
| Country of Origin | Vietnam |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Limited Warranty | 3 Year |
| Additional Warranty Information |
|
Technical specifications
Setup checklist: after you receive your UPS →
How long it'll keep your equipment up.
Manufacturer-specified runtime at typical loads. Real-world figures depend on battery age, ambient temperature, and load profile.
Compare with alternatives
The ECO850LCD side by side with UPS from other makers.
-
Xtreme Power Conversion
Xtreme Power A60-850 850 VA / 500 W Standby UPS, 120 V
Compared with ECO850LCD Spec ECO850LCD Xtreme Power Capacity 850 VA / 425 W 850 VA / 500 W Topology Standby Standby Form Tower Tower Input plug NEMA 5-15P NEMA 5-15P Outlets 6 × NEMA 5-15R, 6 × NEMA 5-15R (6 on battery) 5 × NEMA 5-15R, 5 × NEMA 5-15R (5 on battery) Runtime, half load 9 min 6 min Differences
- 5 battery-backed outlets instead of 6
- Larger unit: 500 W instead of 425 W
$219.81 -
Xtreme Power Conversion
Xtreme Power S71-700 700 VA / 420 W Line-Interactive UPS, 120 V
Compared with ECO850LCD Spec ECO850LCD Xtreme Power Capacity 850 VA / 425 W 700 VA / 420 W Topology Standby Line-Interactive Form Tower Tower Input plug NEMA 5-15P NEMA 5-15P Outlets 6 × NEMA 5-15R, 6 × NEMA 5-15R (6 on battery) 4 × NEMA 5-15R Runtime, half load 9 min 6 min Differences
- 4 battery-backed outlets instead of 6
- Slightly lower rating: 420 W instead of 425 W
- Lower VA rating: 700 VA instead of 850 VA
- Line-interactive, a step up from standby
$243.57
Check outlets and the runtime your load needs before ordering. Questions? Call 438-881-3363 or ask for a quote.
Replacement batteries that fit this exact UPS
A line-interactive UPS typically needs new batteries every 3 to 5 years. Matching replacement cartridges are listed by UPS model; confirm the exact model before ordering.
Questions before you buy
How do I know this UPS will run my equipment?
Add up the wattage draw of every device you'll plug in (servers, switches, monitors). The UPS's wattage rating (not VA) is the number that matters. Aim for the UPS to run at 60 to 70% of capacity at full load: this gives headroom for inrush current and a meaningful runtime margin. Email us your equipment list; we'll respond within one business day with sizing guidance.
What's covered by the warranty, and how long does it last?
New units carry the warranty coverage stated by the manufacturer; see the product listing or manufacturer documentation for the applicable terms. Refurbished units are covered by the 1-year UPSPLUSBATTERY warranty handled in Canada.
Can I extend runtime beyond what's shown above?
Many Smart-UPS-class models accept an external battery pack (XBP) connected to the rear battery port. If this UPS shows "Extended Runtime Capable: Yes" in the spec grid above, an XBP is supported. Compatible XBPs and the runtime gain they deliver vary by model; contact us if you don't see the right XBP in our catalogue.
