| UPC | 0767041027198 |
| Double Conversion | 2U | Optional RDU101 Card| Color/Graphic LCD| 3-Year Warranty | |
| General Information | |
|---|---|
| Manufacturer: | Vertiv |
| Manufacturer Part Number: | GXT52000IRT2UXL |
| Manufacturer Website Address: | http://www.vertiv.com/ |
| Brand Name: | Liebert |
| Product Series: | GXT |
| Product Model: | GXT5-2000IRT2UXL |
| Product Name: | GXT5 UPS - 2000VA/2000W 230V | Online Rack Tower |
| Marketing Information: | The Vertiv Liebert GXT5 UPS 2000VA/2000W, is a 2U UPS solution for ensuring the health and availability of IT infrastructure. With online, double conversion technology, the UPS protects critical equipment against outages and every type of power disturbance without drawing on battery power, extending battery life and minimizing replacements. This can support a wide range of power environment including 200/208/220/230/240V user configurable AC power and has scalable runtime options with matching external battery cabinets to offer extra time during an outage to support critical equipment and activity. It includes hot-swappable batteries and all hardware for installing it as a tower or in an equipment rack. This single-phase UPS is ENERGY STAR® 2.0 certified and offers leading normal mode power efficiency and Eco-mode for ultimate efficiency levels. It has a three-year factory warranty. It offers premium power protection for critical infrastructure in centralized and edge applications. |
| Product Condition: | New |
| Product Type: | Double Conversion Online UPS | Technical Information |
| Plug/Connector Type: | IEC 60320 C20 |
| Receptacle Type: | IEC 60320 C13 |
| Receptacle Detail: | 8 x IEC 60320 C13 |
| Protection Type: |
|
| Cord Length: | 10 ft |
| Transfer Time: | 0 ns |
| Phase: | Single Phase |
| Application/Usage: |
|
Power Description |
| Load Capacity (VA): | 2 kVA |
| Load Capacity (Watt): | 2 kW |
| Input Voltage: | 230 V AC |
| Input Voltage Range: | 115 V AC - 288 V AC |
| Output Voltage: |
|
| Input Frequency: | 70 Hz |
| Waveform Type: | Pure Sine Wave |
| Circuit Breaker: | Yes | Controls/Indicators |
| Status Indicators: | Color LCD |
Interfaces/Ports |
| Serial Port: | Yes |
| VGA: | No |
| Modem (RJ-11): | No |
| Network (RJ-45): | Yes |
| USB (HID Compliant) Port: | Yes | Battery Information |
| DC System Voltage: | 48 V DC |
| Number of Batteries: | 3 |
| Battery Characteristics: | Valve-regulated, Non-spillable |
| Battery Chemistry: | Lead Acid |
| Battery Size: | 12V |
| Battery Capacity: | 9000 mAh |
| Backup/Run Time (Full Load): | 3.20 Minute |
| Backup/Run Time (Half Load): | 10.70 Minute |
| Battery Life: | 5 Year |
| Typical Battery Recharge Time: | 4 Hour |
| Hot Pluggable: | Yes |
| Hot Swappable: | Yes |
| Replaceable Battery: | Yes | Environmental Conditions |
| Environmental Sensors: |
|
| Maximum Operating Temperature: | 104°F (40°C) |
| Storage Temperature: | 5°F (-15°C) - 104°F (40°C) |
| Sound Emission: | 48 dB | Physical Characteristics |
| Color Family: | Black |
| Product Color: | Black |
| Height: | 3.35" (85 mm) |
| Width: | 16.93" (430 mm) |
| Depth: | 18.50" (470 mm) |
| Rack Height: | 2U |
| Form Factor: | Rack/Tower |
| Weight (Approximate): | 21 kg | Miscellaneous |
| Package Contents: |
|
| Certifications & Standards: |
|
| Software Included: | Free Download - Power Insight 2.2 |
| Energy Star: | Yes |
| Country of Origin: | China |
| TAA Compliant: | No |
| Environmentally Friendly: | Yes |
| Environmental Compliance: |
|
Warranty |
| Limited Warranty: | 3 Year |
