About this UPS
- Brand: Tripp Lite by Eaton
- Product Type: Line-interactive UPS
- Manufacturer Part Number: OMNIVS1500
- Input Voltage: 110 V AC
- Form Factor: Tower
- Plug/Connector Type: NEMA 5-15P
- Product Family: Omni VS
- Backup/Run Time (Half Load): 14 Minute
- Backup/Run Time (Full Load): 5 Minute
- Load Capacity: 1.50 kVA/940 W
Marketing Information:
Tripp Lite's OMNIVS1500 line interactive UPS system offers voltage regulation, surge suppression and battery support for sensitive electronics. Internal UPS batteries support entry level PC systems for up to 75 minutes during power failures. Automatic Voltage Regulation (AVR) circuits regulate brownouts as low as 75 and overvoltages up to 147 volts back to usable 120V levels without using battery power. Includes 5 battery supported outlets plus 3 additional surge suppression only outlets. USB port enables optional unattended system shutdown. PowerAlert software available via free download from www.tripplite.com. Built-in data line suppression for equipment with single line TEL/DSL or network Ethernet. Built-in audible alarm and 5 front panel LEDs. 1500VA power handling ability. Offers 4 minutes battery runtime with a full load of 1500VA and 8.5 minutes with a half load of 750VA. Supports hot-swappable battery replacement via built-in access panel.
| PRODUCT SPECIFICATIONS | |
|---|---|
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 8 x NEMA 5-15R |
| Dataline Protection |
|
| Transfer Time | 4 ms |
| Load Capacity (VA) | 1.50 kVA |
| Load Capacity (Watt) | 940 W |
| Input Voltage | 110 V AC |
| Input Current | 12 A |
| Output Voltage | 120 V AC |
| USB | Yes |
| Backup/Run Time (Full Load) | 5 Minute |
| Backup/Run Time (Half Load) | 14 Minute |
| Typical Battery Recharge Time | 4 Hour |
| Hot Swappable | Yes |
| Height | 11.75" (298.45 mm) |
| Width | 7.25" (184.15 mm) |
| Depth | 7.50" (190.50 mm) |
| Form Factor | Tower |
| Weight (Approximate) | 27.78 lb (12600 g) |
| Package Contents |
|
| Additional Information |
|
| Certifications & Standards | Tested to UL1778 (USA), CSA C22.2 No. 107.3 (Canada), NOM (Mexico), Class A (emissions), FCC Part 68 / Industry Canada (Telecommunications) |
| Country of Origin | China |
| Limited Warranty | 3 Year |
Technical specifications
Setup checklist: after you receive your UPS →
How long it'll keep your equipment up.
Manufacturer-specified runtime at typical loads. Real-world figures depend on battery age, ambient temperature, and load profile.
Compare with alternatives
The OMNIVS1500 side by side with UPS from other makers.
-
Xtreme Power Conversion
Xtreme Power S71-1500 1500 VA / 900 W Line-Interactive UPS, 120 V
Compared with OMNIVS1500 Spec OMNIVS1500 Xtreme Power Capacity 1500 VA / 940 W 1500 VA / 900 W Topology Line-Interactive Line-Interactive Form Tower Tower Input plug NEMA 5-15P NEMA 5-15P Outlets 5 × NEMA 5-15R, 3 × NEMA 5-15R (5 on battery) 6 × NEMA 5-15R Runtime, half load 12 min Not stated Differences
- Slightly lower rating: 900 W instead of 940 W
$522.80 -
Xtreme Power Conversion
Xtreme Power P80-1100 1100 VA / 990 W Line-Interactive UPS, 120 V
Compared with OMNIVS1500 Spec OMNIVS1500 Xtreme Power Capacity 1500 VA / 940 W 1100 VA / 990 W Topology Line-Interactive Line-Interactive Form Tower Tower/Rack Convertible, 2U Input plug NEMA 5-15P NEMA 5-15P Outlets 5 × NEMA 5-15R, 3 × NEMA 5-15R (5 on battery) 8 × NEMA 5-15R Runtime, half load 12 min 11 min Differences
- Lower VA rating: 1100 VA instead of 1500 VA
$1,096.42 -
Xtreme Power Conversion
Xtreme Power P91-1000 1000 VA / 1000 W Online UPS, 120 V
Compared with OMNIVS1500 Spec OMNIVS1500 Xtreme Power Capacity 1500 VA / 940 W 1000 VA / 1000 W Topology Line-Interactive Online Double-Conversion Form Tower Tower/Rack Convertible, 2U Input plug NEMA 5-15P NEMA 5-15P Outlets 5 × NEMA 5-15R, 3 × NEMA 5-15R (5 on battery) 8 × NEMA 5-15R Runtime, half load 12 min 10 min Differences
- Lower VA rating: 1000 VA instead of 1500 VA
- Online double-conversion, a step up from line-interactive
$1,385.60
Check outlets and the runtime your load needs before ordering. Questions? Call 438-881-3363 or ask for a quote.
Replacement batteries that fit this exact UPS
A line-interactive UPS typically needs new batteries every 3 to 5 years. Matching replacement cartridges are listed by UPS model; confirm the exact model before ordering.
Questions before you buy
How do I know this UPS will run my equipment?
Add up the wattage draw of every device you'll plug in (servers, switches, monitors). The UPS's wattage rating (not VA) is the number that matters. Aim for the UPS to run at 60 to 70% of capacity at full load: this gives headroom for inrush current and a meaningful runtime margin. Email us your equipment list; we'll respond within one business day with sizing guidance.
What's covered by the warranty, and how long does it last?
New units carry the warranty coverage stated by the manufacturer; see the product listing or manufacturer documentation for the applicable terms. Refurbished units are covered by the 1-year UPSPLUSBATTERY warranty handled in Canada.
Can I extend runtime beyond what's shown above?
Many Smart-UPS-class models accept an external battery pack (XBP) connected to the rear battery port. If this UPS shows "Extended Runtime Capable: Yes" in the spec grid above, an XBP is supported. Compatible XBPs and the runtime gain they deliver vary by model; contact us if you don't see the right XBP in our catalogue.
