About this UPS
- Brand: Tripp Lite by Eaton
- Product Type: Line-interactive UPS
- Manufacturer Part Number: SMART1300LCDT
- Input Voltage: 110 V AC
- Form Factor: Tower
- Plug/Connector Type: NEMA 5-15P
- Product Family: Smart-LCD SmartPro
- Backup/Run Time (Half Load): 10 Minute
- Load Capacity: 1.30 kVA/720 W
- Provides 1300VA/720W high-performance power protection for desktop computers, audio/video components, media centers and other electronics
- Supports basic desktop computer and LCD monitor up to 64 minutes during power outage
- Supports 50% load (360W) up to 10 minutes
- Audible alarm indicates loss of utility power or low battery
- 4 NEMA 5-15R outlets deliver battery backup for devices that require constant power
- All 8 outlets protect against surges or spikes that can harm equipment or data
- NEMA 5-15P plug with 6-ft. (1.83 m) cord connects to any NEMA 5-15R socket
- Corrects undervoltages as low as 92V and overvoltages as high as 150V without drawing battery backup power
- Large LCD screen shows real-time voltage, load, AVR and battery statuses
- Automatically displays remaining battery runtime in minutes during power outage
- Surge suppression rating of 650 joules protects connected equipment and data from harmful power surges
- Tel/DSL RJ11 jacks protect standard dialup/DSL/Ethernet phone connection
- Coaxial jacks protect CATV, broadband cable internet, satellite or broadcast antenna connection
- Removes electromagnetic and radio frequency interference that can disrupt or damage your equipment's performance
Marketing Information:
The SMART1300LCDT SmartPro LCD 120V, 1300VA/720W Line-Interactive Uninterruptible Power Supply provides battery backup and AC power protection against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. Ideal for backing up your desktop computer or audio/visual components, this line-interactive UPS switches to battery backup mode in milliseconds to keep your connected equipment running long enough to save files and shut down safely with no data loss.
While all eight NEMA 5-15R outlets protect against surges, four outlets also provide up to 64 minutes of UPS battery support for a basic desktop PC and LCD monitor and up to 10 minutes of support at half load (360W).
Automatic voltage regulation (AVR) corrects undervoltages as low as 92V and overvoltages as high as 150V without using any battery power. EMI/RFI noise filtering improves your equipment's performance and prevents damage. A 650-joule surge suppression rating protects your equipment from harmful power surges.
NEMA 5-15P plug with 6-ft. (1.83 m) cord connects to any NEMA 5-15R socket. Large LCD screen shows real-time input voltage, overload, AVR, remaining battery runtime and battery statuses at a glance. Alarm sounds to indicate power loss or low battery. With Tripp Lite's free PowerAlert software (available via free web download), the SMART1300LCDT enables safe unattended system shutdown and file saves in case of a prolonged power failure.
Reliable Battery Backup
Optimized Outlets
Automatic Voltage Regulation (AVR)
LCD Status Screen
AC Line, Coaxial and Tel/DSL Surge Suppression
EMI/RFI Line Noise Filtering
| PRODUCT SPECIFICATIONS | |
|---|---|
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 4 x NEMA 5-15R |
| Transfer Time | 6 ms |
| Load Capacity (VA) | 1.30 kVA |
| Load Capacity (Watt) | 720 W |
| Input Voltage | 110 V AC |
| Output Voltage | 120 V AC |
| Serial Port | Yes |
| USB | Yes |
| Backup/Run Time (Half Load) | 10 Minute |
| Typical Battery Recharge Time | 6.30 Hour |
| Height | 8" (203.20 mm) |
| Width | 5.75" (146.05 mm) |
| Depth | 15.40" (391.16 mm) |
| Form Factor | Tower |
| Weight (Approximate) | 26.50 lb (12020.20 g) |
| Package Contents |
|
| Certifications & Standards |
|
| Country of Origin | Vietnam |
| TAA Compliant | No |
| Limited Warranty | 3 Year |
Technical specifications
Setup checklist: after you receive your UPS →
How long it'll keep your equipment up.
Manufacturer-specified runtime at typical loads. Real-world figures depend on battery age, ambient temperature, and load profile.
Compare with alternatives
The SMART1300LCDT side by side with UPS from other makers.
-
Xtreme Power Conversion
Xtreme Power P80-800 800 VA / 720 W Line-Interactive UPS, 120 V
Compared with SMART1300LCDT Spec SMART1300LCDT Xtreme Power Capacity 1300 VA / 720 W 800 VA / 720 W Topology Line-Interactive Line-Interactive Form Tower Tower/Rack Convertible, 2U Input plug NEMA 5-15P NEMA 5-15P Outlets 4 × NEMA 5-15R, 4 × NEMA 5-15R (4 on battery) 8 × NEMA 5-15R Runtime, half load 10 min 11 min Differences
- Lower VA rating: 800 VA instead of 1300 VA
$1,068.18 -
Xtreme Power Conversion
Xtreme Power S71-1500 1500 VA / 900 W Line-Interactive UPS, 120 V
Compared with SMART1300LCDT Spec SMART1300LCDT Xtreme Power Capacity 1300 VA / 720 W 1500 VA / 900 W Topology Line-Interactive Line-Interactive Form Tower Tower Input plug NEMA 5-15P NEMA 5-15P Outlets 4 × NEMA 5-15R, 4 × NEMA 5-15R (4 on battery) 6 × NEMA 5-15R Runtime, half load 10 min Not stated Differences
- Larger unit: 900 W instead of 720 W
$522.80 -
Xtreme Power Conversion
Xtreme Power T91-700 700 VA / 700 W Online UPS, 120 V
Compared with SMART1300LCDT Spec SMART1300LCDT Xtreme Power Capacity 1300 VA / 720 W 700 VA / 700 W Topology Line-Interactive Online Double-Conversion Form Tower Tower Input plug NEMA 5-15P NEMA 5-15P Outlets 4 × NEMA 5-15R, 4 × NEMA 5-15R (4 on battery) 6 × NEMA 5-15R Runtime, half load 10 min 16 min Differences
- Slightly lower rating: 700 W instead of 720 W
- Lower VA rating: 700 VA instead of 1300 VA
- Online double-conversion, a step up from line-interactive
$975.80 Request a freight quote
Check outlets and the runtime your load needs before ordering. Questions? Call 438-881-3363 or ask for a quote.
Replacement batteries that fit this exact UPS
A line-interactive UPS typically needs new batteries every 3 to 5 years. Matching replacement cartridges are listed by UPS model; confirm the exact model before ordering.
Questions before you buy
How do I know this UPS will run my equipment?
Add up the wattage draw of every device you'll plug in (servers, switches, monitors). The UPS's wattage rating (not VA) is the number that matters. Aim for the UPS to run at 60 to 70% of capacity at full load: this gives headroom for inrush current and a meaningful runtime margin. Email us your equipment list; we'll respond within one business day with sizing guidance.
What's covered by the warranty, and how long does it last?
New units carry the warranty coverage stated by the manufacturer; see the product listing or manufacturer documentation for the applicable terms. Refurbished units are covered by the 1-year UPSPLUSBATTERY warranty handled in Canada.
Can I extend runtime beyond what's shown above?
Many Smart-UPS-class models accept an external battery pack (XBP) connected to the rear battery port. If this UPS shows "Extended Runtime Capable: Yes" in the spec grid above, an XBP is supported. Compatible XBPs and the runtime gain they deliver vary by model; contact us if you don't see the right XBP in our catalogue.
