| UPC | 0731304433651 |
| AVR - 3 Hour Recharge - 7 Minute Stand-by - 120 V Input - 120 V AC Output - Serial Port - 6 x NEMA 5-15R - 6 x Battery/Surge Outlet - TAA Compliant | |
| General Information | |
|---|---|
| Manufacturer: | Schneider Electric SA |
| Manufacturer Part Number: | SMT1500RMX93 |
| Manufacturer Website Address: | http://www.schneider-electric.com |
| Brand Name: | APC by Schneider Electric |
| Product Line: | Smart-UPS |
| Product Name: | Smart-UPS 1.5kVA 120V RM SHIPBOARD |
| Marketing Information: | Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices. |
| Product Type: | Line-interactive UPS |
| Technical Information | |
| AVR: | Yes |
| Plug/Connector Type: | NEMA 5-15P |
| Receptacle Type: | NEMA 5-15P |
| Receptacle Detail: | 6 x NEMA 5-15R |
| Number of Battery & Surge Outlets: | 6 |
| Transfer Time: | 10 ms |
| Power Description | |
| Load Capacity (VA): | 1.44 kVA |
| Load Capacity (Watt): | 1 kW |
| Input Voltage: | 120 V |
| Input Voltage Range: | 82 V AC - 144 V AC |
| Output Voltage: | 120 V AC |
| Input Frequency: | 60 Hz |
| Output Frequency: | 60 Hz |
| Waveform Type: | Sine Wave |
| Surge Energy Rating: | 693 J |
| Management | |
| Alarm: | Changing Utility Power |
| Controls/Indicators | |
| Status Indicators: |
LED Display:
|
| Interfaces/Ports | |
| Serial Port: | Yes |
| USB (HID Compliant) Port: | Yes |
| Battery Information | |
| Battery Chemistry: | Lead Acid |
| Battery Energy: | 1555.2 kJ |
| Backup/Run Time (Full Load): | 7 Minute |
| Backup/Run Time (Half Load): | 26 Minute |
| Battery Life: | 5 Year |
| Typical Battery Recharge Time: | 3 Hour |
| Environmental Conditions | |
| Maximum Operating Temperature: | 104°F (40°C) |
| Storage Temperature: | -4°F (-20°C) - 131°F (55°C) |
| Storage Relative Humidity: | 0% - 95% |
| Sound Emission (A-Weighted): | 45 dB(A) |
| Thermal Dissipation: | 255 BTU/h |
| Physical Characteristics | |
| Height: | 3.39" (86 mm) |
| Width: | 17.01" (432 mm) |
| Depth: | 18.78" (477 mm) |
| Form Factor: | Rack-mountable |
| Mounting Location: | Front |
| Weight (Approximate): | 26.50 kg |
| Miscellaneous | |
| Certifications & Standards: | CSA C22.2 No 107.1 |
| Green Premium: | Yes |
| Mercury Free: | Yes |
| RoHS Exemption Information: | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SMT1500RMX93_ROHS_DECLARATION&p_FileName=SMT1500RMX93KIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL: | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=559241382&lang=en-us |
| EU RoHS Declaration URL: | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=559241382&lang=en-us |
| Environmental Profile Availability: | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612029_EN |
| End of Life Manual Availability: | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612029_EN |
| WEEE Statement: | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Country of Origin: | United States |
| TAA Compliant: | Yes |
| Environmentally Friendly: | Yes |
| Environmental Compliance: | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty: | 3 Year |
| Additional Warranty Information: | 3 years repair or replace (excluding battery) and 2 years for battery |
Call us if more information required.
