APC by Schneider Electric Industrial Panel and DIN Rail UPS with Standard Battery 500VA 120V - SUA500PDR-S
APC by Schneider Electric Industrial Panel and DIN Rail UPS with Standard Battery 500VA 120V - SUA500PDR-S
- Ships from our Canadian warehouse — CAD pricing, no customs
- New in box — manufacturer warranty applies
- Purchase orders / Net-30 welcome (B2B & public sector)
Questions? 438-881-3363 · Mon–Fri
About this UPS
APC by Schneider Electric Industrial Panel and DIN Rail UPS with Standard Battery 500VA 120V
| UPC | 9999999999999 |
| 1U Tower - 2 Hour Recharge - 8 Minute Stand-by - 120 V Input - 120 V AC Output - Sine Wave - Serial Port - 1 x Hard Wire 3-wire (H N + G) - 1 x Battery/Surge Outlet | |
| General Information | |
|---|---|
| Manufacturer: | Schneider Electric SA |
| Manufacturer Part Number: | SUA500PDR-S |
| Manufacturer Website Address: | http://www.schneider-electric.com |
| Brand Name: | APC by Schneider Electric |
| Product Name: | Industrial Panel and DIN Rail UPS with Standard Battery 500VA 120V |
| Marketing Information: | Proven Industrial UPS power protection for control applications and harsh environments. |
| Product Type: | Line-interactive UPS | Technical Information |
| Plug/Connector Type: | Hard Wire 3 wire (1PH+N+G) |
| Receptacle Type: | Hard Wire 3-wire (H N + G) |
| Receptacle Detail: | 1 x Hard Wire 3-wire (H N + G) |
| Number of Battery & Surge Outlets: | 1 |
| Emergency Power OFF: | Yes |
| Cord Length: | 8 ft | Power Description |
| Load Capacity (VA): | 500 VA |
| Load Capacity (Watt): | 325 W |
| Input Voltage: | 120 V |
| Output Voltage: | 120 V AC |
| Waveform Type: | Sine Wave |
| Surge Energy Rating: | 540 J | Interfaces/Ports |
| Serial Port: | Yes |
| Total Number of Expansion Slots: | 1 | Battery Information |
| Battery Characteristics: | Maintenance-free, Sealed |
| Battery Chemistry: | Lead Acid |
| Backup/Run Time (Full Load): | 8 Minute |
| Backup/Run Time (Half Load): | 24 Minute |
| Typical Battery Recharge Time: | 2 Hour | Physical Characteristics |
| Color Family: | Black |
| Product Color: | Black |
| Height: | 5.83" (148 mm) |
| Width: | 14.25" (362 mm) |
| Depth: | 6.73" (171 mm) |
| Rack Height: | 1U |
| Form Factor: | Tower |
| Weight (Approximate): | 12.86 kg | Miscellaneous |
| Package Contents: |
|
| Certifications & Standards: | UL Recognized |
| Green Premium: | Yes |
| Optimized Energy Efficiency: | Yes |
| Product Take Back Program: | Yes |
| Mercury Free: | Yes |
| RoHS Exemption Information: | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SUA500PDR-S_ROHS_DECLARATION&p_FileName=SUA500PDR-SKIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL: | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=323194164&lang=en-us |
| EU RoHS Declaration URL: | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=323194164&lang=en-us |
| Environmental Profile Availability: | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612028_EN |
| End of Life Manual Availability: | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612028_EN |
| California Proposition 65 Warning: | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| REACH free of SVHC: | No |
| Environmentally Friendly: | Yes |
| Environmental Compliance: | Restriction of Hazardous Substances (RoHS) | Warranty |
| Limited Warranty: | 2 Year |
| Additional Warranty Information: | 2 years repair or replace |
Technical specifications
How long it'll keep your equipment up.
Manufacturer-specified runtime at typical loads. Real-world figures depend on battery age, ambient temperature, and load profile.
Estimate based on manufacturer-specified runtime curve. Real-world runtime varies with battery age, ambient temperature, and load profile.
Compatible accessories
Network management cards, rail kits, environmental sensors — verified compatible with this UPS line.
Before you order
How do I know this UPS will run my equipment?
Add up the wattage draw of every device you'll plug in (servers, switches, monitors). The UPS's wattage rating — not VA — is the number that matters. Aim for the UPS to run at 60–70% of capacity at full load: this gives headroom for inrush current and a meaningful runtime margin. Email us your equipment list and we'll size the right UPS within one business hour.
What's covered by the warranty, and how long does it last?
New units carry the full manufacturer warranty registered to you on receipt. The manufacturer handles claims directly via their North American support channel. Refurbished units are covered by our own 1-year UPSPLUSBATTERY warranty handled in-house in Canada.
Can I extend runtime beyond what's shown above?
Many Smart-UPS-class models accept an external battery pack (XBP) connected to the rear battery port. If this UPS shows "Extended Runtime Capable: Yes" in the spec grid above, an XBP is supported. Compatible XBPs and the runtime gain they deliver vary by model — contact us if you don't see the right XBP in our catalogue.
