Tripp Lite SMART5000RT3U 5000 VA Rack/Tower Line Interactive UPS - SMART5000RT3U - Line-interactive UPS, 220 V AC, Sine Wave, 6U, 208 V AC, NEMA L6-30P, SmartPro, 38 Minute, 16 Minute, 5 kVA/4 kW
Tripp Lite SMART5000RT3U 5000 VA Rack/Tower Line Interactive UPS - SMART5000RT3U - Line-interactive UPS, 220 V AC, Sine Wave, 6U, 208 V AC, NEMA L6-30P, SmartPro, 38 Minute, 16 Minute, 5 kVA/4 kW
- Ships from our Canadian warehouse — CAD pricing, no customs
- New in box — manufacturer warranty applies
- Purchase orders / Net-30 welcome (B2B & public sector)
Questions? 438-881-3363 · Mon–Fri
About this UPS
- Brand: Tripp Lite by Eaton
- Product Type: Line-interactive UPS
- Manufacturer Part Number: SMART5000RT3U
- Input Voltage: 220 V AC
- Waveform Type: Sine Wave
- Rack Height: 6U
- Plug/Connector Type: NEMA L6-30P
- Product Family: SmartPro
- Backup/Run Time (Half Load): 38 Minute
- Backup/Run Time (Full Load): 16 Minute
- Load Capacity: 5 kVA/4 kW
Marketing Information:
Tripp Lite's line-interactive SMART5000RT3U UPS System protects server, networking or telecommunications equipment from blackouts, voltage fluctuations and surges in a compact tower/rackmount housing. Large capacity 5000VA/4000W power module converts raw 208V AC input to fully regulated dual output 208/120 voltage for simultaneous protection of both high- and low-voltage equipment loads. True sine wave output at all times offers guaranteed compatibility with all equipment types. Includes 14 outlets, 8 of which can be individually reset via software interface to selectively reboot remote equipment or shed less critical loads to extend battery runtime for more critical equipment. Includes slot for internal SNMP/web card, plus two DB9 and two USB enhanced monitoring ports for unattended shutdown, remote control and monitoring of UPS system and power data. 2 Year Warranty standard. 3 Year Warranty with product registration.
| PRODUCT SPECIFICATIONS | |
|---|---|
| Plug/Connector Type | NEMA L6-30P |
| Receptacle Type |
|
| Receptacle Detail |
|
| Emergency Power OFF | Yes |
| Cord Length | 10 ft (3.05 m) |
| Transfer Time | 4 ms |
| Load Capacity (VA) | 5 kVA |
| Load Capacity (Watt) | 4 kW |
| Input Voltage | 220 V AC |
| Output Voltage | 208 V AC |
| Waveform Type | Sine Wave |
| Network Management | SNMP Manageable |
| Alarm |
|
| Status Indicators | 5 front panel LEDs - Green 5 front panel LEDs - Green POWER LED, Green VOLTAGE CORRECTION LED, 3 color BATTERY CHARGE LED, 3 color OUTPUT LOAD LED, red BATTERY WARNING LED |
| USB | Yes |
| Total Number of Expansion Slots | 1 |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 16 Minute |
| Backup/Run Time (Half Load) | 38 Minute |
| Battery Life | 6 Year |
| Typical Battery Recharge Time | 4 Hour |
| Hot Swappable | Yes |
| Maximum Operating Temperature | 104 °F (40 °C) |
| Height | 3.50" (88.90 mm) |
| Width | 17.25" (438.15 mm) |
| Depth | 16.75" (425.45 mm) |
| Rack Height | 6U |
| Weight (Approximate) | 58.50 lb (26535.15 g) |
| Package Contents |
|
| Additional Information |
|
| Certifications & Standards | UL1778 (USA), cUL (Canada), FCC Class A (emissions), NOM (Mexico), Conforms to IEEE 587 / ANSI C62.41 specifications |
| Country of Origin | China |
| Limited Warranty | 3 Year |
Technical specifications
How long it'll keep your equipment up.
Manufacturer-specified runtime at typical loads. Real-world figures depend on battery age, ambient temperature, and load profile.
Need more runtime? This UPS accepts external battery packs (XBPs). Contact us about XBP options →
Estimate based on manufacturer-specified runtime curve. Real-world runtime varies with battery age, ambient temperature, and load profile.
Compatible accessories
Network management cards, rail kits, environmental sensors — verified compatible with this UPS line.
Replacement batteries that fit this exact UPS
A line-interactive UPS typically needs new batteries every 3–5 years. We stock the matching replacement cartridges — Canadian warranty.
Before you order
How do I know this UPS will run my equipment?
Add up the wattage draw of every device you'll plug in (servers, switches, monitors). The UPS's wattage rating — not VA — is the number that matters. Aim for the UPS to run at 60–70% of capacity at full load: this gives headroom for inrush current and a meaningful runtime margin. Email us your equipment list and we'll size the right UPS within one business hour.
What's covered by the warranty, and how long does it last?
New units carry the full manufacturer warranty registered to you on receipt. The manufacturer handles claims directly via their North American support channel. Refurbished units are covered by our own 1-year UPSPLUSBATTERY warranty handled in-house in Canada.
Can I extend runtime beyond what's shown above?
Many Smart-UPS-class models accept an external battery pack (XBP) connected to the rear battery port. If this UPS shows "Extended Runtime Capable: Yes" in the spec grid above, an XBP is supported. Compatible XBPs and the runtime gain they deliver vary by model — contact us if you don't see the right XBP in our catalogue.
