About this UPS
Tripp Lite by Eaton OmniSmart OMNISMART550MX 550VA Ultra-compact Desktop/Tower/Wall Mount UPS
| UPC | 0037332256096 |
| Ultra-compact Desktop/Tower/Wall Mount - AVR - 5 Hour Recharge - 3.60 Minute Stand-by - 120 V AC Input - 120 V AC Output - Single Phase - 12 x NEMA 5-15R - 6 x Battery/Surge Outlet | |
| General Information | |
|---|---|
| Manufacturer: | Tripp Lite by Eaton |
| Manufacturer Part Number: | OMNISMART550MX |
| Manufacturer Website Address: | https://tripplite.eaton.com/ |
| Brand Name: | Tripp Lite by Eaton |
| Product Line: | OmniSmart |
| Product Model: | OMNISMART550MX |
| Product Name: | OmniSmart OMNISMART550MX 550VA Ultra-compact Desktop/Tower/Wall Mount UPS |
| Marketing Information: |
550VA/340W/120V Battery Backup for PCs, Home Theaters or Digital Signage Allows Time to Back Up Critical Files During a Blackout 12 NEMA 5-15R Outlets Protect Your Connected Components Double-Boost AVR Corrects Low/High-Voltage Conditions for Enhanced Performance 600 Joules Fight Back Against Unexpected Power Surges Designed for High Efficiency to Help You Save Money and Protect the Environment |
| Product Type: | Line-interactive UPS | Technical Information |
| AVR: | Yes |
| Plug/Connector Type: | NEMA 5-15P |
| Receptacle Type: | NEMA 5-15R |
| Receptacle Detail: | 12 x NEMA 5-15R |
| Number of Battery & Surge Outlets: | 6 |
| Number of Surge-only Outlets: | 6 |
| Dataline Protection: | RS-232 |
| Transfer Time: | 6 ms |
| EMI/RFI Noise Filter: | Yes |
| Phase: | Single Phase |
| Energy Saving: | Greater than 95% efficiency - GREEN UPS |
| Application/Usage: |
|
Power Description |
| Load Capacity (VA): | 540 VA |
| Load Capacity (Watt): | 340 W |
| Input Voltage: | 120 V AC |
| Output Voltage: | 120 V AC |
| Input Frequency: | 60 Hz |
| Output Frequency: | 60 Hz |
| Waveform Type: | Pure Sine Wave |
| Surge Energy Rating: | 600 J | Management |
| Alarm: |
|
Controls/Indicators |
| Status Indicators: |
LED Indicators:
|
Interfaces/Ports |
| USB (HID Compliant) Port: | Yes | Battery Information |
| DC System Voltage: | 12 V DC |
| Backup/Run Time (Full Load): | 3.60 Minute |
| Backup/Run Time (Half Load): | 10 Minute |
| Typical Battery Recharge Time: | 5 Hour |
| Replaceable Battery: | Yes | Environmental Conditions |
| Maximum Operating Temperature: | 104 °F (40 °C) |
| Storage Temperature: | 5 °F (-15 °C) - 104 °F (40 °C) |
| Maximum Operating Elevation: | 10000 ft (3048000 mm) |
| Thermal Dissipation: | 23.21 BTU/h | Physical Characteristics |
| Height: | 4.13" (105 mm) |
| Width: | 7.48" (190 mm) |
| Depth: | 12.01" (305 mm) |
| Form Factor: | Ultra-compact Desktop/Tower/Wall Mount |
| Weight (Approximate): | 5.50 kg | Miscellaneous |
| Package Contents: |
|
| Energy Star: | Yes |
| Country of Origin: | China |
| Environmentally Friendly: | Yes |
| Environmental Compliance: | Restriction of Hazardous Substances (RoHS) | Warranty |
| Limited Warranty: | 2 Year |
Technical specifications
How long it'll keep your equipment up.
Manufacturer-specified runtime at typical loads. Real-world figures depend on battery age, ambient temperature, and load profile.
Estimate based on manufacturer-specified runtime curve. Real-world runtime varies with battery age, ambient temperature, and load profile.
Replacement batteries that fit this exact UPS
A line-interactive UPS typically needs new batteries every 3–5 years. We stock the matching replacement cartridges — Canadian warranty.
Before you order
How do I know this UPS will run my equipment?
Add up the wattage draw of every device you'll plug in (servers, switches, monitors). The UPS's wattage rating — not VA — is the number that matters. Aim for the UPS to run at 60–70% of capacity at full load: this gives headroom for inrush current and a meaningful runtime margin. Email us your equipment list and we'll size the right UPS within one business hour.
What's covered by the warranty, and how long does it last?
New units carry the full manufacturer warranty registered to you on receipt. The manufacturer handles claims directly via their North American support channel. Refurbished units are covered by our own 1-year UPSPLUSBATTERY warranty handled in-house in Canada.
Can I extend runtime beyond what's shown above?
Many Smart-UPS-class models accept an external battery pack (XBP) connected to the rear battery port. If this UPS shows "Extended Runtime Capable: Yes" in the spec grid above, an XBP is supported. Compatible XBPs and the runtime gain they deliver vary by model — contact us if you don't see the right XBP in our catalogue.
