| UPC | 0037332211064 |
| Ultra-compact Desktop/Tower/Wall Mount - 6.50 Hour Recharge - 1.20 Minute Stand-by - 120 V AC Input - 110 V AC, 115 V AC, 120 V AC Output - Single Phase - Pure Sine Wave - USB - 10 x NEMA 5-15R | |
| General Information | |
|---|---|
| Manufacturer: | Tripp Lite by Eaton |
| Manufacturer Part Number: | ECO550UPS |
| Manufacturer Website Address: | https://tripplite.eaton.com/ |
| Brand Name: | Tripp Lite by Eaton |
| Product Series: | ECO |
| Product Model: | ECO550UPS |
| Product Name: | ECO550UPS 550VA Ultra-compact Desktop/Tower/Wall Mount UPS |
| Marketing Information: |
Backup support allows you to work through short power failures and gives you enough time to safely save files and shut down your system in case of a prolonged blackout. Backup time varies according to load, but the ECO550UPS should keep an energy-efficient desktop computer with small LCD monitor powered as long as 16 minutes. During normal operation, incoming utility power keeps the replaceable internal battery fully charged, so backup power will always be available.
Five 5-15R outlets provide battery backup and surge protection for your computer, monitor and other crucial components. The other five 5-15R outlets provide surge suppression only for printers, speakers and other desktop equipment regarded as non-essential during a blackout.
By meeting strict EPA efficiency guidelines, this ENERGY STAR-certified UPS system helps you save money and energy. An ECO power-saving option features three switched ECO outlets (two surge-only, one surge- and battery-protected) that turn off automatically when the device connected to the Battery Backup Master Outlet is powered down or in sleep mode. These outlets are recommended for printers, desk lamps and other non-essential peripherals that don't need to be operational all the time.
A 316-joule surge suppression rating protects connected components from the harmful effects of power surges.
This USB port connects the ECO550UPS to a computer running free downloadable PowerAlert® software to enable safe unattended file saves and system shutdown in case of a prolonged power failure. USB cable is included.
Various electromagnetic and radio sources found in virtually every home and business can cause disruptive interference on the AC line. Known as EMI (electromagnetic interference) and RFI (radio frequency interference), this line noise is a common cause of performance problems and can lead to incremental hardware damage, data corruption and audio/video transmission problems. The ECO550UPS incorporates technology that filters out disruptive line noise so that it won't affect your equipment.
The UPS remains silent in both line and battery backup modes. The alarm sounds only to warn you of a low battery, overload or fault condition. A front-panel green LED indicates operating mode, ECO mode and fault status. |
| Packaged Quantity: | 1 Each |
| Product Type: | Standby UPS | Technical Information |
| Plug/Connector Type: | NEMA 5-15P |
| Receptacle Type: | NEMA 5-15R |
| Receptacle Detail: | 10 x NEMA 5-15R |
| Number of Surge-only Outlets: | 5 |
| Dataline Protection: | RJ-11 |
| Protection Type: |
|
| Overload Protection: | Yes |
| Cord Length: | 6 ft |
| Transfer Time: | 6 ms |
| Phase: | Single Phase |
| Application/Usage: |
|
Power Description |
| Load Capacity (VA): | 550 VA |
| Load Capacity (Watt): | 300 W |
| Input Voltage: | 120 V AC |
| Output Voltage: |
|
| Output Frequency: | 60 Hz |
| Waveform Type: | Pure Sine Wave |
| Surge Energy Rating: | 316 J | Management |
| Alarm: |
|
Controls/Indicators |
| Status Indicators: |
2 LED Indicator:
Main Power Switch Controls :
|
Interfaces/Ports |
| USB: | Yes |
| USB (HID Compliant) Port: | Yes | Battery Information |
| DC System Voltage: | 12 V DC |
| Battery Characteristics: | Valve-regulated |
| Battery Chemistry: | Lead Acid |
| Backup/Run Time (Full Load): | 1.20 Minute |
| Backup/Run Time (Half Load): | 5 Minute |
| Battery Life: | 6 Year |
| Typical Battery Recharge Time: | 6.50 Hour |
| Replaceable Battery: | Yes | Environmental Conditions |
| Minimum Operating Temperature: | 32°F (0°C) |
| Maximum Operating Temperature: | 104°F (40°C) |
| Storage Temperature: | 5°F (-15°C) - 133°F (56.1°C) |
| Maximum Storage Elevation: | 6561 ft (1999792.80 mm) |
| Sound Emission: | 40 dB |
| Thermal Dissipation: | 4 BTU/h | Physical Characteristics |
| Color Family: | Black |
| Product Color: | Black |
| Height: | 4.13" (105 mm) |
| Width: | 4.33" (110 mm) |
| Depth: | 7.28" (185 mm) |
| Form Factor: | Ultra-compact Desktop/Tower/Wall Mount |
| Weight (Approximate): | 2.36 kg | Miscellaneous |
| Package Contents: |
|
| Additional Information: |
|
| Certifications & Standards: |
Tested to :
|
| Software Included: | PowerAlert software available via free download |
| Recycled: | No |
| Assembly Required: | No |
| Energy Star: | Yes |
| Country of Origin: | Vietnam |
| Environmentally Friendly: | Yes |
| Energy Efficiency Certification: | ENERGY STAR 2.0 |
| Environmental Compliance: | Restriction of Hazardous Substances (RoHS) | Warranty |
| Limited Warranty: | 3 Year |
| Additional Warranty Information: |
|
