About this UPS
Product Features:
- Brand: Tripp Lite by Eaton
- Product Type: Line-interactive UPS
- Manufacturer Part Number: SMART2200RM2UL
- Input Voltage: 120 V AC
- Form Factor: Rack-mountable
- Waveform Type: Pure Sine Wave
- Rack Height: 2U
- Plug/Connector Type: NEMA 5-20P
- Product Family: SmartPro
- Backup/Run Time (Half Load): 11.70 Minute
- Backup/Run Time (Full Load): 5.10 Minute
- Load Capacity: 2.20 kVA/1.92 kW
- Provides fully regulated sine wave AC output for servers, network storage devices, telecom hardware and other applications where long battery lifespan is critical
- Audible alarm signals loss of utility power, overload and low battery
- 4 NEMA 5-15R & 4 NEMA 5-15/20R outlets
- 10-ft. (3.05 m) power cord with 120V NEMA 5-20P input
- 570-joule surge suppression rating
- 0.9 power factor rating
- 97% line-mode efficiency rating saves money in energy costs
- More than 2x the service life
- Up to 3x more charge/discharge cycles
- Recharges to 100% capacity in less than 2 hr.
- Weighs 60% less, reducing overall UPS weight
- Supports half load up to 11.7 min. and full load up to 5.1 min.
- Can control 2 outlets remotely to reboot equipment or shed nonessential loads
- Maintains 120V nominal output over input range of 83V-145V without using battery power
- Removes electromagnetic and radio frequency interference that can disrupt or damage equipment's performance
- Front-panel LCD with detailed UPS and site power status and operating data
- Rotates for easy viewing in rack-mount or tower configurations
- Compatible with Tripp Lite UPS management cards WEBCARDLX, SNMPWEBCARD and RELAYIOCARD
- USB and DB9 ports enable data-saving unattended shutdown when used with Tripp Lite PowerAlert software (available via free download at
- www.tripplite.com/poweralert
- EPO port supports emergency shutdown in large facilities
- Hardware included for 4-post mounting in 2U of EIA-standard 19 in. rack
- Mounts on wall or 2-post rack with optional 2POSTRMKITWM accessory
- Mounts in upright tower position with optional 2-9USTAND accessory
- $250,000 Ultimate Lifetime Insurance covers any connected components
Marketing Information: Protects Mission-Critical Rack-Mounted Equipment
Product Specifications:
Product Features:
| PRODUCT SPECIFICATIONS | |
|---|---|
| Plug/Connector Type | NEMA 5-20P |
| Receptacle Type |
|
| Receptacle Detail |
|
| Protection Type |
|
| Emergency Power OFF | Yes |
| Transfer Time | 5 ms |
| EMI/RFI Noise Filter | Yes |
| Phase | Single Phase |
| Application/Usage |
|
| Load Capacity (VA) | 2.20 kVA |
| Load Capacity (Watt) | 1.92 kW |
| Input Voltage | 120 V AC |
| Input Current | 16 A |
| Output Voltage |
|
| Waveform Type | Pure Sine Wave |
| Surge Energy Rating | 570 J |
| Circuit Breaker | Yes |
| Alarm |
|
| Serial Port | Yes |
| USB | Yes |
| Backup/Run Time (Full Load) | 5.10 Minute |
| Backup/Run Time (Half Load) | 11.70 Minute |
| Typical Battery Recharge Time | 1.40 Hour |
| Hot Swappable | Yes |
| Maximum Operating Temperature | 122 °F (50 °C) |
| Sound Emission (A-Weighted) | 45 dB(A) |
| Thermal Dissipation | 1343 BTU/h |
| Height | 3.43" (87 mm) |
| Width | 19.45" (494 mm) |
| Depth | 17.32" (440 mm) |
| Rack Height | 2U |
| Form Factor | Rack-mountable |
| Weight (Approximate) | 41.78 lb (18950 g) |
| Package Contents |
|
| Certifications & Standards |
|
| Country of Origin | United States |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Limited Warranty | 5 Year |
Technical specifications
Power
VA Rating
2200VA
Wattage
1920W
Topology
Line-Interactive
Waveform
Pure Sine Wave
Input
Input Voltage
120V
Input Plug
NEMA 5-20P (T-slot 20A)
Output
Output Voltage
110V
Receptacles
4× NEMA 5-154× NEMA 5-20
Features
Form Factor
Rackmount 2U
Connectivity
["USB""RS-232 Serial""HTTP/Web Management"]
Extended Runtime Capable
true
Condition
New
Operating Temperature
0 to 50 °C (32 to 122 °F)
Dimensions
87 × 494 × 440 mm (3.43 × 19.45 × 17.32 in)
Weight
18.95kg
Manufacturer Warranty
5 years
Backup runtime
How long it'll keep your equipment up.
Manufacturer-specified runtime at typical loads. Real-world figures depend on battery age, ambient temperature, and load profile.
Half load (960 W)
12.0 min
Full load (1920 W)
5.1 min
Need more runtime? This UPS accepts external battery packs (XBPs). Contact us about XBP options →
W
Estimated runtime
—min
Estimate based on manufacturer-specified runtime curve. Real-world runtime varies with battery age, ambient temperature, and load profile.
Shipped across Canada
Shipped from our Canadian warehouse. See shipping policy for rates and timing.
Manufacturer-backed
New UPS units carry the full manufacturer warranty registered to you on receipt.
14 years in business
UPSPLUSBATTERY has supplied Canadian UPS systems since 2012.
Sizing & install help
Email your load profile — we'll spec the right UPS within one business hour.
Before you order
How do I know this UPS will run my equipment?
Add up the wattage draw of every device you'll plug in (servers, switches, monitors). The UPS's wattage rating — not VA — is the number that matters. Aim for the UPS to run at 60–70% of capacity at full load: this gives headroom for inrush current and a meaningful runtime margin. Email us your equipment list and we'll size the right UPS within one business hour.
What's covered by the warranty, and how long does it last?
New units carry the full manufacturer warranty registered to you on receipt. The manufacturer handles claims directly via their North American support channel. Refurbished units are covered by our own 1-year UPSPLUSBATTERY warranty handled in-house in Canada.
Can I extend runtime beyond what's shown above?
Many Smart-UPS-class models accept an external battery pack (XBP) connected to the rear battery port. If this UPS shows "Extended Runtime Capable: Yes" in the spec grid above, an XBP is supported. Compatible XBPs and the runtime gain they deliver vary by model — contact us if you don't see the right XBP in our catalogue.
